Rehadapt Rehadapter Instructions For Use Manual page 22

To attach the keyguard permanently, the keyguard must be inserted before the tablet is placed in the
Rehadapter. Choose the hard keyguard blocks (black) for a permanent attachment of the keyguard.
To change the keyguard blocks follow these steps:
1. Open the Rehadapter.
2. Remove the tablet.
3. Remove the preassembled keyguard blocks
4. Choose the correct color
5. Attach the keyguard blocks (4x).
5.a. The white and grey keyguard blocks are self-adhesive on one side. When using the white or
grey blocks, attach the keyguards from the front of the Rehadapter after it has been closed
(as shown in Section 4.6).
For a correct positioning, the self-adhesive side of the white and grey keyguard blocks must face the

casing and point towards the outer side of the front casing
Figure 5.4 Positioning the white/grey blocks of the keyguard click system
5.b. When using the black keyguard blocks, insert the keyguards before closing the Rehadapter.
For a correct insertion, the textured side of the black keyguard blocks must face the outer side of the

front casing. Insert this side first and press on the two remaining corners until they click into place
5 5 . . 5 5 ) )
.
Figure 5.5 Positioning the black blocks of the keyguard click system
6. Insert the tablet.
Make sure the tablet is positioned correctly.

( ( 5 5 . . 1 1 . . 1 1 O O p p e e n n i i n n g g t t h h e e R R e e h h a a d d a a p p t t e e r r ™ ™ ) )
( ( 5 5 . . 1 1 . . 2 2 I I n n s s e e r r t t i i n n g g t t h h e e T T a a b b l l e e t t ) )
( ( s s e e e e t t a a b b l l e e a a b b o o v v e e ) )
( ( 5 5 . . 1 1 . . 2 2 I I n n s s e e r r t t i i n n g g t t h h e e T T a a b b l l e e t t ) )
2 2 2 2

(4x) from the front casing
depending on the use of the keyguards.
( ( F F i i g g . . 5 5 . . 4 4 ) )
.
 in the front casing
 in the front casing

.

( ( F F i i g g . .

