- Page 1 Flotilla BRC 45/38 120V English From Serial Number (Ref No. 1*) * See Serial Number page in Spare Parts List or call manufacturer. Register 8.645-280.0-B 03/24/23 your product www.kaercher.com/welcome...
-
Page 2: Machine Data Label
Machine Data Label Overview This carpet extractor is an electrical powered, portable carpet extractor intended for commercial use. The appliance sprays a cleaning solution onto the carpet, agitates the wet carpet, and then extracts the soiled solution back into the unit's recovery tank. The appliance is available with an optional hand tool for cleaning upholstery and stairs. MODEL: 1.008-061.0 BRC 45/38 Kärcher North America Headquarters... -
Page 3: Table Of Contents
Table of Contents Machine Data Label ......2 Overview ........2 Table of Contents . -
Page 4: How To Use This Manual
How To Use This Manual This manual contains the following sections: The SAFETY section contains important information regarding hazardous or unsafe practices of the • How to Use This Manual machine. Levels of hazards are identified that could • Safety result in product damage, personal injury, or severe •... -
Page 5: Safety
Safety Safety Labels NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illeg- ible, promptly replace them. Emplacement De L'étiquette De Sécurité REMARQUE : Ces dessins indiquent l'emplacement des étiquettes de sécurité sur la machine. Si, à tout moment, les étiquettes deviennent illisibles, contactez votre représentant autorisé... -
Page 6: Important Safety Instructions
Safety IMPORTANT SAFETY INSTRUCTIONS When using this machine, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. To reduce the risk of fire, electric shock, or injury: Connect to a properly grounded outlet. See Grounding Instructions. Do not leave the machine unattended. -
Page 7: Consignes De Sécurité Importantes
Safety CONSIGNES DE SÉCURITÉ IMPORTANTES Lors de l'utilisation de cette machine, des précautions de base doivent toujours être prises, y compris les précautions suivantes : LIRE TOUTES LES INSTRUCTIONS AVANT D'UTILISER CETTE MACHINE. Pour réduire le risque d'incendie, d'électrocution ou de blessure : Cet appareil ne doit être connecter qu a des prises ayant une sortie de terre. -
Page 8: Hazard Intensity Level
Safety The following symbols are used throughout this guide as indicated in their descriptions: HAZARD INTENSITY LEVEL There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY. The level of hazard intensity is determined by the following definitions: WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death. -
Page 9: Niveau D'intensité Du Danger
Safety Les symboles suivants sont utilisés dans tout ce manuel, tels que décrits ici : NIVEAU D'INTENSITÉ DU DANGER Il existe trois niveaux d'intensité du danger, identifiés par des termes d'avertissement - AVERTISSEMENT, ATTENTION et POUR VOTRE SÉCURITÉ. Le niveau d'intensité du danger est déterminé par les définitions suivantes : AVERTISSEMENT - Les dangers ou des pratiques contraires à... -
Page 10: Grounding Instructions
Safety Grounding Instructions 120 Volt Models: THIS PRODUCT IS FOR COMMERCIAL This appliance is for use on a nominal 120-volt circuit, and has a grounded plug that looks like the plug in "Fig. USE ONLY. A". A temporary adapter that looks like the adapter in Electrical: "Fig. -
Page 11: Operations
Operations How This Machine Works The function of the scrub system is to scrub the carpet, mix the cleaning solution with the soil and lift and This carpet extractor is an electrical powered, self groom the carpet pile. The scrub system consists of a contained portable carpet extractor intended for cylindrical brush and a motor. -
Page 12: Technical Specification
Operations Technical Specification ITEM MEASURE Height 43 inches (1092.2 mm) Length 37.5 inches (952.5 mm) Width 21.75 inches (552.5 mm) Width of scrub path 19 inches (482.6 mm) This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 13 Operations Technical Specifications ITEM DIMENSION/CAPACITY Construction Plastic Injection-molded chassis with rotationally molded polyethylene tank Three stage, bypass, 1.5 hp (1,119 watts), 100 cfm (2.8m³/min), 120" (3050 Vacuum Motor mm) waterlift 50 psi (3.5 bar) - Interim Solution Pump 100 psi (7 bar) - Restorative Brush Motor .1 hp (xx watts) DC Brush...
-
Page 14: Controls
Operations Controls Display The LED lights in the center are (from left to right): 1. Power 2. Vacuum 3. Brush 4. Solution 5. Eco! Mode. The switch on the left controls the solution flow. The switch on the right allows the operator to reverse the brush motor, effectively moving the machine in an Reverse Solution Switch... -
Page 15: Rear Cover Storage
Operations Display 1. Power Light • Green indicates that the machine has power. • Off indicates the machine does not have power or is set to the off position. • See Trouble Shooting section if Green light is not on when it should be. 2. -
Page 16: Operations - Display 1
Operations - Display 1 Select Mode Screens MODE Used for quiet cleaning with propelling with brushes and HELLO! Eco extract lower vacuum. Select a mode MODE Vacuum-only SPEED Default MODE Encapsulate MODE Speed display icons Used to clean while Deep extract - Default propelling with brushes - Max... -
Page 17: Settings, Configuration, Language
Operations - Display 1 Settings, Configuration, Language Used to set screen language CONFIGURATION LANGUAGE LANGUAGE SETTINGS Language English English Configuration returns to select Machine Hours Deutsch Deutsch Maintenance mode screen Product Page Français Français History LANGUAGE LANGUAGE Deutsch Deutsch Français Français Español Español... -
Page 18: Settings, Maintenance, Guides, Startup
Operations - Display 2 Settings, Maintenance, Guides, Startup Settings, History, Codes Used with connected device to access machine instructions. SETTINGS MAINTENANCE GUIDES STARTUP Configuration Guides Startup Maintenance Shutdown History 10 Hour SHUTDOWN 10 HOUR SETTINGS HISTORY Configuration Codes if NO entries if entries Maintenance History... -
Page 19: Reset The Machine
Operations - Display 2 Reset the Machine If nothing on the machine is turning on, reset the machine by pressing the breaker. This should take care of most issues. If this does not work, contact your service representative. Circuit Breaker 8.645-280.0 Manual Operator Flotilla BRC 45-38... -
Page 20: Errors
Operations - Display 3 Errors if machine turned off and if error BRUSH ERROR BRUSH ERROR BRUSH ERROR is fixed S T O P Unplug Unplug Clean Clean Learn more ERROR BRUSH ERROR BRUSH ERROR BRUSH ERROR Corrected? Yes, continue Turn Turn No, go back... -
Page 21: Check
Operations - Display 3 Check CHECK if error is fixed Fresh water tank ERROR Corrected? CHECK Yes, continue No, go back returns to op Float ball strainer mode screen ERROR Corrected? CHECK Yes, continue No, go back Brush if error is NOT fixed TRIGGER HANDLE if YES... -
Page 22: Components
Operations Components 1. Operator Controls and Display 8. Dirty Water Clear Observation Cover 2. Recovery Lid 9. Recovery Drain Hose 3. Recovery Tank 10. Control Height Adjustment - Operator Controls 4. Scrub Deck 11. Deep Extraction Jets 5. Solution Fill Cover 12. -
Page 23: Pre Run Setup
Operations Pre Run Setup OPERATION 1. To unfold handle, loosen knob, rotate upper STORAGE steering column and steering wheel back to stop. Tighten knob. STEP 1 2. Install the vacuum shoe and brush. Fill solution tank with water and chemical. (see Filling the Solution Tank instructions). -
Page 24: Filling The Solution Tank
Operations Filling The Solution Tank Do not put defoamer or solvent chemicals in the REMOVE solution tank. SOLUTION FILL COVER Do not allow water to spill into vacuum motor inlet. Dry spills from top of solution tank. Do not tip machine on back when full as water may spill from machine. -
Page 25: Operating The Machine
Operations Operating The Machine 1. Select a mode from the Main Control Membrane Switch for the desired results. See Display section for detailed description of each function. STEP 1 2. Turn on Solution Switch. • Press the bottom of the switch to turn solution •... - Page 26 Operations Operating The Machine - continued 3. Squeeze the large Yellow Trigger Switch to make the machine move, run the brush and dispense solution. Use the steering wheel to guide the machine in the intended direction. Press the bottom of the Reverse Switch to make the machine travel backward while the yellow trigger switch is depressed.
- Page 27 Operations 5. During operation, observe the following: STEP 5 VACUUM INTAKE This machine is equipped with clear dome to facili- tate operator viewing of dirty solution and vacuum SOLUTION INTAKE air flow. During operation, observe the vacuum intake: Any amount of water or foam entering the vacuum system can damage the vacuum motor.
-
Page 28: To Clean Under Desks Or Dead End Hallways
Operations To Clean Under Desks Or Dead End 11. When finished for the day, prop recovery lid open to allow tank to dry and to decrease odors. Drain any Hallways extra clean solution and prop open the solution fill By activating the momentary reverse switch, the brush lid. -
Page 29: Accessory Tool Connection And Use
Operations Accessory Tool Connection and Use NOTE: Use only manufacturer supplied accessory tools. See Optional Accessories section. ° 1. Spin the deck 180 so that the vacuum shoe is at the front of the machine. 2. To connect solution hose pull back collar and insert over machine mounted fitting, then release collar to lock into place. -
Page 30: Maintenance
Maintenance Service Schedule MAINTENANCE DAILY WEEKLY QUARTERLY Check machine for cord damage Check recovery dome and gasket for damage and cleanliness Check brushes - should be clean with no lint or strings attached Clean the underside of the brush deck area Observe spray pattern Inspect vac shoe for blockage;... -
Page 31: Components
Maintenance Components 1. Brush 5. Solution Strainer 2. Deep Extraction Jets 6. Spray Jet - Interim 3. Float Shut-off 7. Vacuum Shoe 4. Solution Drain Hose 8.645-280.0 Manual Operator Flotilla BRC 45-38... -
Page 32: Periodic Maintenance
Maintenance Periodic Maintenance Daily / Regular Maintenance NOTE: Before making any adjustments or repairs to the 1. Empty unused cleaning solution from the solution machine, disconnect the power cord from electrical tank. source 2. Flush pumping system with 4 to 7 liters of clean, hot water. -
Page 33: Vacuum Shoe Cleaning
Maintenance Vacuum Shoe and Hose Vacuum Shoe Cleaning NOTE: Vacuum Shoe and hose flush should be done 1. Unplug the power cord and move the machine to a daily after use. Place machine over drainage area safe level area. before beginning. 2. -
Page 34: Scrub Deck
Maintenance Scrub Deck 1. Drive Motor 2. Scrub Brush 3. Scrub Brush Motor (Transmission cover not shown) 4. Vacuum Motor 5. Solution Pump Only qualified maintenance personnel are to perform the following repairs. Seul le personnel d'entretien qualifié peut effectuer des réparations. 8.645-280.0 Manual Operator Flotilla BRC 45-38... -
Page 35: Scrub Head Maintenance
Maintenance Scrub Head Maintenance Scrub Brush Replacement The cylindrical scrub head is designed to scrub chemicals into the carpet and propel the machine. Only use the brush provided with the appliance or those specified in the instructions manual. The use The Scrub brush should be replaced when the brush is of other brushes may impair safety. -
Page 36: Circuit Protection
Maintenance Circuit Protection Circuit breakers interrupt the flow of power in the event of an electrical overload. When a circuit breaker is tripped, reset it by pressing the button. If a circuit breaker continues to trip, contact your service representative. Circuit Breaker 8.645-280.0 Manual Operator Flotilla BRC 45-38... -
Page 37: Suggested Spare Parts
Suggested Spare Parts 86426430 RECOVERY DRAIN HOSE 86003630 FLOAT SHUT-OFF 86424140 PUMP 86004570 JET BODY (3) 86454460 JET MINI PROMAX 86405000 ROLLER BRUSH 86412780 JET MINI PROMAX (2) 86403040 SOLUTION HOSE 86414120 VACUUM MOTOR 86409460 STRAINER 8.645-280.0 Manual Operator Flotilla BRC 45-38... - Page 38 THANK YOU! DANKE! MERCI! GRACIAS! Register your product and benefit from many advantages. Enregistrez votre produit et bénéficiez de nombreux avantages. Registre su producto y aproveche de muchas ventajas. Registrieren Sie Ihr Prudukt und Sie von vielen Vorteilen. www.kaercher.com/welcome Rate your product and tell us your opinion. Évaluez votre produit et donnez-nous votre opinion.
