- Page 1 Assembly GSP20 Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this setup manual...
- Page 3 Notes on the products Before using the ground stack plate , carefully read the assembly instructions and keep the Read manual instructions in a safe place together with the GSP20 ground stack plate . before use! General Information Assembly Guide: OM -GSP20 Version 2.0 d, 11/2022...
-
Page 4: Table Of Contents
Ground stack of the VERA20 loudspeaker ............. 11 VERA20 ground stack setup, from the 2nd loudspeaker ........14 Usage GSP20 on subwoofers as gound stack for VERA20 ........18 5. Transport and Storage ....................20 6. CE Declaration of Conformity ..................21... -
Page 5: Safety | Intended Use
The GSP20 ground stack plate may only be used by trained and qualified personnel. Personnel must check the GSP20 for its full suitability before each use. WARNING When visible damage to any part of the GSP20 ground stack plate is detected, it must be decommissioned immediately. WARNING... - Page 6 VERA20 loudspeakers and subwoofers, ensure that there is enough room to avoid collisions with other objects. WARNING When installing the GSP20 ground stack plate, be careful not to pinch or twist the power cables or other cables of the VERA20 loudspeakers and subwoofers! The respective national electrotechnical regulations apply.
-
Page 7: Overview
Assembly Instructions GSP20 2. Overview Components Figure 2.1 - Overview GSP20 ground stack plate - Surface powder-coated Captive M20 screw connector Captive Quick-locking pin... -
Page 8: Technical Specifications
Assembly Instructions GSP20 3. Technical specifications Data sheet maximum load capacity 8 VERA20 Dimensions (h x w x d) 35 x 550 x 555 mm [1.38 x 21.65 x 21.85 in] Weight 6,2 kg [13.67 lbs.] Surface Powder-coated Maximum length of system setup, 2,40 m [7.87 ft.]... -
Page 9: Commissioning
Make sure that all system structures are located on a firm, level surface and that the surface can bear the total weight! WARNING TW AUDiO recommends using only the accessories specified by TW AUDiO for securing and mounting the ground stack plate . NOTE... -
Page 10: Danger Of Tipping Over
M20 screw connector connects GSP20 ground stack plate to the subwoofer! Depending on the subwoofer model, use the appropriate mounting hole in the GSP20. Be WARNING sure to keep the center of gravity of the VERA20 loudspeaker assembly above the subwoo- fer. -
Page 11: Ground Stack Of The Vera20 Loudspeaker
2. Both splay links in the front rigging tracks must be extended downwards. NOTE Figure 4.6.1 - Loosen quick-locking pins 3. Have two persons place the VERA20 loudspeaker on the GSP20 ground stack plate. 4. Pull back the VERA20 loudspeaker until its splay links align with the recesses of the NOTE GSP20 ground stack plate. - Page 12 Figure 4.6.4 - Pull the hook down 8. Select the appropriate level (number of degrees) for your system setup. See figures 4.6.5 to 4.6.10. 9. Attach the hook to the GSP20 ground stack plate using the quick-locking pin on the WARNING GSP20.
- Page 13 Assembly Instructions GSP20 Figure 4.6.7 - Side view VERA20 loudspeaker 9° downtilt Figure 4.6.8 - Side view VERA20 loudspeaker 6° downtilt Figure 4.6.9 - Side view VERA20 loudspeaker 0° (horizontal) Figure 4.6.10 - Side view VERA20 loudspeaker 6° uptilt...
-
Page 14: Vera20 Ground Stack Setup, From The 2Nd Loudspeaker
Assembly Instructions GSP20 VERA20 ground stack setup, from the 2nd loudspeaker To set up the ground stack array, starting from the second VERA20 loudspeaker, proceed as follows: 1. Loosen the two quick-locking pins at the front of the VERA20 loudspeaker. - Page 15 Assembly Instructions GSP20 5. Insert the VERA20 loudspeaker´s two front quick-locking pins into the holes of the lower loudspeaker. WARNING Figure 4.7.3 - Plug quick-locking pins 6. Use the left slider on the lower VERA20 loudspeaker´s rear rigging to select the angle for the next upper speaker.
- Page 16 Assembly Instructions GSP20 7. Loosen the quick-locking pin on the main carrier of the upper VERA20 loudspeaker´s rear rigging and fold out the hook by 90°. 8. Lift the upper VERA20 loudspeaker at the rear and pull the hook all the way down so that WARNING it aligns with the rear rigging of the lower VERA20 loudspeaker.
- Page 17 Assembly Instructions GSP20 11. Move the right slider of the lower loudspeaker to the left until it displays the same number of degrees as the left slider. This fixes the upper loudspeaker. WARNING Figure 4.7.7 - Move right slider 12. Follow the instructions in this section of the manual to connect up to eight VERA20 loudspe- akers.
-
Page 18: Usage Gsp20 On Subwoofers As Gound Stack For Vera20
VERA20 loudspeakers GSP20 ground stack plate always requires two persons! WARNING Please note that the GSP20 ground stack plate must rest flat on the subwoofer and cover it in full! WARNING Always ensure that the stability of the entire system assembly is guaranteed, especially if it is... - Page 19 Assembly Instructions GSP20 Figure 4.8 - System setup ground stack...
-
Page 20: Transport And Storage
Assembly Instructions GSP20 5. Transport and Storage Ensure that the surface of the ground stack plate is not damaged during transport and sto- rage. Moisture may penetrate where steel surfaces are exposed by scratches and result in corrosion. NOTE This is why the product should be transported and stored in a safe, careful, dry and largely dust-free manner. -
Page 21: Ce Declaration Of Conformity
Assembly Instructions GSP20 6. CE Declaration of Conformity Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 22 Assembly Instructions GSP20 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
