SAFETY INSTRUCTIONS
FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY
RESULT IN SERIOUS INJURY,
PROPERTY DAMAGE AND WILL VOID WARRANTY.
This unit is intended for display purposes only and
should not be used for play.
To ensure safety, do not attempt to assemble this system without
following the instructions carefully. Check entire box and inside all
packing material for parts. Before beginning assembly, read the
instructions and identify parts in this document. Proper and
complete assembly, use and supervision is essential for proper
operation and to reduce the risk of accident or injury. A high
probability of serious injury exists if this system is not installed,
maintained, and operated properly.
• During assembly, if using a ladder use extreme caution. Two
people are recommended for this operation.
• If technical assistance is required, contact Huffy Sports' Sample
and Display Technician.
• Serious injury could occur if teeth/face come in contact with
backboard, net or rim.
• Display recommended for 3" (7.6 cm) or 3-1/2" (9 cm) Round or 4"
(10 cm) Square poles only.
• All instructions and warnings MUST accompany any display item
that is sold.
Most injuries are caused by misuse and/or not following
Use caution when installing this unit.
IMPORTANT!
To ensure prompt and correct handling of any problems, or to answer any questions, please contact the Sample
and Display Technician at 1-800-558-5234.
Model 89224
instructions.
Internet Address: http://www.huffysports.com
REQUIRED TOOLS AND
• Wrenches: (Two each) 7/16", 1/2", 9/16",
and 3/4" or Pliers
• Step Ladder, 8 ft. (2.4 m)
1
Customer Service
N53 W24700 South Corporate Circle
Sussex, WI 53089
U.S.A.
MATERIALS:
P/N 211678A
06/03
Advertisement
Table of Contents
Related Manuals for Huffy 89224
Summary of Contents for Huffy 89224
- Page 1 • During assembly, if using a ladder use extreme caution. Two people are recommended for this operation. • If technical assistance is required, contact Huffy Sports’ Sample and Display Technician. • Serious injury could occur if teeth/face come in contact with backboard, net or rim.
- Page 2 PARTS LIST Item Qty. Part No. Description 901097 Extension Arm 207103 Pole Cap for 3.5” Pole Section 203100 Nut, Hex Flange 5/16-18* 201611 Bolt, Hex Flange, 5/16-18 x 3” 203218 Washer, Flat, 5/16* 200516 Bolt Cover, Vinyl* 908812 3.5” Pole Section 202460 Saddle Clamp 201763...
- Page 3 48” Fan Backboard 44” Fan (Remains in 44” Fan center location) Backboard CURRENT INSTALLATION DIAGRAM EXACTA HEIGHT POLE ASSEMBLY: REMOVE & DISCARD 44” Steel Framed Acrylic OR IT MAY BE LOCATED IN A DIFFERENT CORNER. FRONT The side with pegboard on the top and bottom.
- Page 4 WARNING Install pole mounting hardware and pole for each assembly. TWO PEOPLE ARE NECESSARY TO MOUNT THE ELEVATOR ASSEMBLY TO THE POLE. ONE PERSON SHOULD NOT ATTEMPT TO DO THIS ALONE. 3-1/2” Rnd. Pole X 30” Pole Upper Support Railing 3-1/2”...
- Page 5 INSTALLATION DIAGRAM WARNING Assemble display products per diagram below. TWO PERSON MINIMUM REQUIRED FOR THIS PROCEDURE. NOT FOLLOWING RECOMMENDATION MAY RESULT IN BODILY INJURY. 48” Fan Backboard 44” Fan 44” Fan FRONT 44” Rectangle 48” Rectangle Steel Steel Framed Framed Acrylic Acrylic P/N 211678A 06/03...
- Page 6 Refer To Combo For Goal Assembly Instructions Mount extension arm and rim to backboard and finger tighten as shown. NOTE: For spring loaded rim assembly, refer to instructions included with rim hardware. Secure hardware to extension arm as shown and tighten completely.
