Foreword General This manual introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, WARNING could result in slight or moderate injury.
Page 3
If there is any uncertainty or controversy, we reserve the right of final explanation. ...
Important Safeguards and Warnings Electrical Safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited Power Source requirement according to IEC60950-1.
Page 5
Do not touch the image sensor directly (CMOS). Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. Device body can be cleaned with soft dry cloth, which can also be used to remove stubborn ...
Table of Contents Foreword ................................I Important Safeguards and Warnings ......................III 1 Cable ................................1 2 Network Configuration ..........................2 Initializing Device ..................................2 Modifying Device IP Address ..............................3 Logging in to Web Interface..............................4 3 Installation ..............................5 Packing List ....................................
Cable Cable type might vary with different devices, and the actual product shall prevail. Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1.
Network Configuration Device initialization and IP address setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB operation manual. Device initialization is available on select models, and it is required at first use or after the device ...
The password setting interface is displayed. See Figure 2-2. Figure 2-2 Password setting Step 7 Set and confirm the password of the devices, then enter a valid email address, and then click Next. The final setting interface is displayed. Password can be modified or reset in System Settings. Step 8 Select the options according to your needs, and then click OK.
Figure 2-3 Modify IP Address Select Static mode, and then enter start IP, subnet mask, and gateway. Step 3 IP addresses of multiple devices will be set to the same if you select the Same IP checkbox. If DHCP server is available in the network, devices will automatically obtain IP ...
Installation Packing List The tool required for the installation such as electric drill is not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. Dimension Following figures are for reference only, and the actual product shall prevail.
Installing Device 3.3.1 Installation Type 3.3.2 Attaching Device Make sure the mounting surface is strong enough to hold at least three times of the weight of the device and bracket.
