- Page 1 Dahua HD Mobile Network Camera Quick Start Guide Dahua HD Mobile Network Camera Quick Start Guide Version 1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
-
Page 2: Important Safeguards And Warnings
Dahua HD Mobile Network Camera Quick Start Guide Welcome Thank you for purchasing our network cameras. This user’s manual is designed to be a reference tool for using your product. Please read the following safeguards and warnings carefully before you use this series product. - Page 3 Dahua HD Mobile Network Camera Quick Start Guide Do not dismantle the device because there is no component that can be fixed by users themselves. Otherwise, it might cause water leakage or bad image due to unprofessional dismantling. Please contact after-sale service to replace desiccant when it becomes green.
-
Page 4: Regulatory Information
Dahua HD Mobile Network Camera Quick Start Guide The company is not liable for any loss caused by the operation that does not comply with the manual. If there is any uncertainty or controversy, please refer to our final explanation. -
Page 5: Table Of Contents
Dahua HD Mobile Network Camera Quick Start Guide Table of Contents 1 Device Framework ..........................1 1.1 Structure and dimension ....................... 1 1.2 Dimension ............................. 2 1.3 Alarm Setup ........................... 3 2 Device Installation ..........................6 3 Network Configuration........................10 3.1 Modify IP Address ........................ -
Page 6: Device Framework
Dahua HD Mobile Network Camera Quick Start Guide 1 Device Framework 1.1 Structure and dimension Note The following structure figures are for reference only. They are only used to know the functions of structure components and cable ports. There might be some minor differences between different devices, so please refer ... -
Page 7: Dimension
Dahua HD Mobile Network Camera Quick Start Guide Port name Function description It includes alarm input and output. Different devices have different I/O ports. Actual use shall be in accordance with I/O port device label, refer to Table 1-2 for more details. -
Page 8: Alarm Setup
Dahua HD Mobile Network Camera Quick Start Guide Figure 1-4 1.3 Alarm Setup Note This function is only supported by some models. The following figure shows the Alarm setup screen. Figure 1-5 To set up the Alarm input and output, do the following: Step 1 Connect alarm input device to the alarm input port of I/O cable. - Page 9 Dahua HD Mobile Network Camera Quick Start Guide Step 4 Set alarm output on the WEB, alarm output corresponds to the alarm output port of the device, which is the alarm output port of I/O port cable. Refer to Figure 1-6 for alarm input and output.
- Page 10 Dahua HD Mobile Network Camera Quick Start Guide Mode B: Switch application. Alarm output is used to drive external circuit. The Max current is 30mA and Max voltage is 5V, and it is advised to add a relay when it is beyond the value.
-
Page 11: Device Installation
Dahua HD Mobile Network Camera Quick Start Guide 2 Device Installation Note The following figures are for reference only, please refer to the product for more details. Make sure the bracket installation surface can sustain at least 3X weight of the total weight of bracket and camera. - Page 12 Dahua HD Mobile Network Camera Quick Start Guide Figure 2-2 Note Long press the reset button for 10s with power on if it needs to restore the device factory settings. Step 3 Fix the device on the installation surface. Take out the installation position map from the accessory bag, paste it on the installation surface according to the monitoring area.
- Page 13 Dahua HD Mobile Network Camera Quick Start Guide Figure 2-3 Note The angle adjustment range of the lens is (-20°～0°) vertically and (-15°～+15°) horizontally, the image rotation direction is (0°～ +360°). Step 5 Take up the upper cover and align it with the screw hole sites on the pedestal, put the cover back in place.
- Page 14 Dahua HD Mobile Network Camera Quick Start Guide fastening cover, make the crystal connector of network cable and then insert it into the network cable. Put the main body of waterproof connector on the network port and rotate it clockwise to lock the network port and waterproof connector firmly.
-
Page 15: Network Configuration
Dahua HD Mobile Network Camera Quick Start Guide 3 Network Configuration The IP address of all the cameras is the same when leaving factory (default IP 192.168.1.108). To make the camera access to the network smoothly, please plan the available IP segment reasonably according to the actual network environment. -
Page 16: Login Web Interface
Dahua HD Mobile Network Camera Quick Start Guide Figure 3-2 Step 5 Set the mode as Static, and input the planned Start IP, Subnet Mask and Gateway. Note Set the mode as DHCP when there is DHCP server in the network, the device will automatically acquire IP address from the DHCP server. - Page 17 Dahua HD Mobile Network Camera Quick Start Guide Note The default username and password is admin and admin respectively, please modify the administrator password as soon as possible after you successfully logged in. Step 3 Click Here to Download Plug-in, and then install controls according to the system prompt.
