Vandal Proof Dome Network Camera
Quick Start Guide
V1.0.2
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Advertisement

Table of Contents
loading

Summary of Contents for Dahua IPC-HDBW2831E-S-S2

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua IPC- HDBW2831E-S-S2 o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Vandal Proof Dome Network Camera Quick Start Guide V1.0.2 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
  • Page 2: Foreword

    Foreword General This manual introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
  • Page 3 regions. For detailed information, see the paper manual, CD-ROM, QR code or our official website. If there is inconsistency between paper manual and the electronic version, the electronic version shall prevail.  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the manual.
  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings Electrical safety  All installation and operation should conform to your local electrical safety codes.  The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 5 protection effect.  It is recommended connect the grounding hole to the ground to enhance the reliability of the device.  Do not touch the image sensor directly (CMOS). Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. ...
  • Page 6: Table Of Contents

    Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III 1 Introduction ............................1 1.1 Cable ............................. 1 1.2 Connecting Alarm Input/output ..................... 2 2 Network Configuration.......................... 4 2.1 Initializing Device .......................... 4 2.2 Modifying Device IP Address ......................5 2.3 Logging in Web Interface ......................
  • Page 7: Introduction

    Introduction 1.1 Cable  Cable type might vary with different devices, and the actual product shall prevail.  Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1.
  • Page 8: Connecting Alarm Input/Output

    Name Description Includes alarm signal input and output ports, the number of I/O Alarm I/O ports might vary on different devices. For detailed information, see "Table 1-2 Alarm information." Inputs 12V DC power. Please be sure to supply power as instructed in the Guide.
  • Page 9 Figure 1-3 Alarm output Step 3 Log in web interface, and configure alarm input and alarm output in alarm setting. The alarm input in the web interface is corresponding to the alarm input end of the  I/O port. There will be high level and low level alarm signal generated by the alarm input device when alarm occurs, set the input mode to "NO"...
  • Page 10: Network Configuration

    Network Configuration Device initialization and IP setting can be finished with the "ConfigTool" or in web interface. For more information, see the WEB Operation Manual.  Device initialization is available on select models, and it is required at first use and after device is being reset.
  • Page 11: Modifying Device Ip Address

    All the devices found in the network segment are listed. Step 5 Select one or several devices which Status are Uninitialized, and then click Initialize. The Device initialization interface is displayed. Step 6 Select the devices that need initialization, and then click Initialize. The password setting interface is displayed.
  • Page 12: Logging In Web Interface

    notice. Step 2 Select the devices which IP addresses need to be modified, and then click Modify IP. The Modify IP Address interface is displayed. See Figure 2-3. Figure 2-3 Modify IP Address interface Step 3 Select Static mode and enter start IP, subnet mask and gateway. ...
  • Page 13 Figure 2-4 Main interface Network Configuration 7...
  • Page 14: Installation

    Installation 3.1 Packing List  The tools required for the installation including electric drill is not provided in the packing.  The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. 3.2 Dimension Following figures are for reference only, the actual product shall prevail.
  • Page 15: Installing Device

    3.3 Installing Device 3.3.1 Installation method、 3.3.2 Installing SD Card (Optional) SD card slot is available on select models. Disconnect the power from the device before installing the SD card. Installation 9...
  • Page 16: Attaching Device

    Pressing reset button: Short press reset button for 1-2 s, press WPS button on the router and the device can be  connected to corresponding router within 1 minute (only supported by some models). Press the reset button for 10 seconds to reset the device. ...
  • Page 17 Cable going through the side cable tray Installation 11...
  • Page 18: Installing Waterproof Connector

    3.3.4 Installing Waterproof Connector This part is only needed when there is waterproof connector come with the device and the device is used outdoor. Installation 12...
  • Page 19: Adjusting Angle

    3.3.5 Adjusting Angle  Vertical rotation ring is available on select models, which fails to support image rotation. Please refer to the real model for more details.  IR light layout is different according to different models; please refer to the real model for more details.
  • Page 20 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. Address: No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Postcode: 310053 Tel: +86-571-87688883 Fax: +86-571-87688815 Email: overseas@dahuatech.com Website: www.dahuasecurity.com Installation 14...
