  • Page 1 SAFE -T-SCOPE ® 7 ” R E A R V I E W B A C K U P C A M E R A S Y S T E M S STSK7165 INSTALLATION / USER MANUAL...
  • Page 2: Maintenance

    STSK7165 USER MANUAL STSK7165 USER MANUAL WARNING 1. To prevent electrical shock, DO NOT OPEN THE MONITOR CASE. There are dangerous voltages inside the monitor. There are no user serviceable parts inside. 2. Avoid exposing monitor to water, rain, moisture etc. It is NOT waterproof. Any moisture inside the monitor could cause extensive damage.
  • Page 3 STSK7165 USER MANUAL STSK7165 USER MANUAL STSK7165 COLOR BACKUP CAMERA SYSTEM INTRODUCTION Please read this manual thoroughly. This manual contains instructions to make the installation of the camera and monitor easier. The color backup camera system is a supplement to standard rearview mirror systems, and will provide additional rearview vision when installed and maintained properly.
  • Page 4: Installation Instructions

    STSK7165 USER MANUAL STSK7165 USER MANUAL INSTALLATION INSTRUCTIONS WIRING CAMERA AND MONITOR 1. See wiring diagram for connections to ignition, ground and “backup lights” circuit. Note: The following instructions are for typical rearview application. (See Fig. 5.) STSC101 CAMERA 2. Before drilling, be sure no cable or wire is on the other side. Be sure to drill a 20mm (0.8in) diameter hole only.
  • Page 5: Functions And Operations

    STSK7165 USER MANUAL STSK7165 USER MANUAL FUNCTIONS AND OPERATIONS HOW TO SET YOUR MONITOR TO YOUR REQUIREMENTS MONITOR NOTE: On-screen menu commands may only be selected when monitor is in Steady-on (green light) mode. When monitor is in standby mode, and activated 1.
  • Page 6: Specifications

    STSK7165 USER MANUAL STSK7165 USER MANUAL SPECIFICATIONS STSC101 CAMERA PICK-UP DEVICE 1/3” Sharp CCD TV SYSTEM NTSC PICTURE ELEMENTS 976(H) x 494(V) SYNCHRONIZATION INTERNAL HORIZONTAL RESOLUTION 750 TV LINES REQUIRED ILLUMINATION 0 LUX MINIMUM POWER SUPPLY 12Vdc POWER CONSUMPTION < 3w @12 VDC CURRENT CONSUMPTION <...
  • Page 7 STSK7165 USER MANUAL STSK7165 USER MANUAL Fig. 3...
  • Page 8 STSK7165 USER MANUAL STSK7165 USER MANUAL Note: For typical single camera installation, this trigger wire should be connected to the vehicle’s “back up lights” circuit, and the rear-view camera should be attached to the connector marked “CA3”...
  • Page 9 A CENTURY OF AUTOMOTIVE VISION SAFETY 90-21 144th Place, Jamaica, New York 11435 TEL (800) 227- 2095 • FAX (718) 297- 0323 techsupport@roscovision.com www.roscovision.com Lit. P/N: M012617C Lit. Rev Date: Jan 26, 2017...
