- Page 1 DASP600L Spray Gun USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. WARNING SYMBOLS AND DEFINITIONS ....................2 2. IMPORTANT SAFETY INSTRUCTIONS ....................2 3. TOOL USE AND CARE ..........................3 4. SERVICE ..............................3 5. AIR SOURCE ............................3 6. SYMBOL DEFINITIONS ........................... 4 7. SPECIFIC SAFETY INSTRUCTIONS ....................... 4 8. -
Page 3: Warning Symbols And Definitions
Keep this manual for the safety warnings and precautions, assembly, operating, inspection, mainte- nance and cleaning procedures. NOTICE Clean the Spray Gun IMMEDIATELY after EVERY use, in between coats, and when it will be idle for more than 5 minutes. Delayed or inadequate cleaning will permanently clog the Spray Gun. -
Page 4: Tool Use And Care
Personal Safety a. Stay alert. Watch what you are doing and use common sense when operating the tool. Do not use the tool while tired or under the influence of drugs, alcohol, or medication. A moment of inatten- tion while operating the tool increases the risk of injury to persons. b. -
Page 5: Symbol Definitions
6. SYMBOL DEFINITIONS Symbol Property or Statement Symbol Property or Statement WARNING marking concerning Pounds per square inch of pressure Risk of Eye Injury. Wear ANSI-approved eye protection. Cubic Feet per Minute flow WARNING marking concerning Risk of Respiratory Injury. Cubic Feet per Minute flow SCFM Wear NIOSH-approved respirator. -
Page 6: Specifications
8. SPECIFICATIONS Max spraying pressure: 2.0 - 3.5 bar Spray width: 160 - 260 mm Consumption: 6 CFM Tank capacity: 600 ml Nozzle diameter: 1.4 mm 9. INITIAL SET UP Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. - Page 7 4. The air hose must be long enough to reach the work area with enough extra length to allow free movement while working. 5. Close the in-line shutoff valve between the compressor and the tool. 6. Turn on the air compressor according to the manufacturer’s directions and allow it to build up pressure until it cycles off.
-
Page 8: Operating Instructions
10. OPERATING INSTRUCTIONS Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Inspect tool before use, looking for damaged, loose, and missing parts. If any problems are found, do not use tool until repaired. - Page 9 Note: To prevent damage to the passages, do not use metal objects to clean the Nozzle and Fluid Tip. 5. Clean inside of Spray Gun by pouring warm soapy water into the Fluid Inlet, then run a flexible round brush (sold separately) through the passage between the Fluid Inlet and Nozzle opening. Figure E 6.
- Page 10 SPRAY GUN SETUP ADJUSTMENT WARNING TO PREVENT SERIOUS INJURY: Do not adjust or tamper with any control or component in a way not specifically explained within this manual. Improper adjustment can result in tool failure or other serious hazards. CAUTION! Keep hands away from Trigger while making adjustments. 1.
- Page 11 9. Turn the Fluid Knob clockwise until it reaches a natural stopping point. Figure H 10. Release the trigger. 11. Tighten Collar on Fluid Knob to lock fluid adjustment settings. Air Adjustment: 12. Attach Spray Gun to spray gun regulator (sold separately). Use spray gun regulator to measure airflow PSI.
- Page 12 Turn Pattern Knob counterclockwise (all the way open) to flatten the spray pattern. Turn it clockwise for a round spray pattern - see Figure K: Pattern Adjustment. Round/ Flat/ Closed Open Figure K: Pattern Adjustment Fan Direction: 16. To change the direction of the fan from horizontal to vertical, loosen the Lock Ring and turn the Nozzle 90°.
- Page 13 3. Using two hands, one to steady the Cup and the other to operate the Spray Gun, aim Nozzle at the workpiece. CAUTION! DO NOT STOP WHEN SPRAYING. Spraying materials will start to set and dry as soon as they come in contact with the air. They will cause a permanent clog if not cleared imme- diately.
- Page 14 Solvent Selection: Follow the paint and solvent manufacturer’s recommendations for cleaning, solvent type, and dispo- sal. IMPORTANT: Do not use mineral spirits with latex paints, doing so will make the paint very difficult to remove After Every Use: 1. Use solvent recommended by paint manufacturer. 2.
-
Page 15: User-Maintenance Instructions
Spent Solvent Disposal: After cleaning, dispose of spent solvent according to the solvent manufacturer’s directions and local hazardous waste standards. 11. USER-MAINTENANCE INSTRUCTIONS Procedures not specifically explained in this manual must be performed only by a qualified technician. WARNING TO PREVENT SERIOUS INJURY: Detach the air supply and safely discharge any residual air pressure in the tool before performing any inspection, maintenance, or cleaning procedures. - Page 16 TROUBLESHOOTING - SPRAY PATTERN DIAGNOSIS Note: The drawings on the left below resemble symptoms of spray pattern problems. Refer to the accompanying possible causes and likely solutions to the right. Problem Possible Causes Likely Solutions 1. Pattern Knob partially closed. 1.
-
Page 17: Exploded View And Part List
GENERAL TROUBLESHOOTING CHART Problem Possible Causes Likely Solutions Sputtering Spray 1. Low paint level. 1. Refill. 2. Cup tipped. 2. Hold upright. 3. Clogged Air Vent on Cup. 3. Clean Air Vent hole. 4. Loose Fluid Inlet connection. 4. Tighten Fluid Inlet connection. 5. - Page 18 N° N° Part Name Part Name Atomization components O-ring 9002 fluid nozzle Air volume adjustment seat 5050 9003 fixed ring Air volume adjustment knob 5051 9004 air nozzle seal gasket External teeth straight air inlet connector 5052 fixed ring ring H type cross recessed countersunk head screw 5053 fluid nozzle...
-
Page 19: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 6 months for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 20 Manufactured under license of Daewoo International Corporation, Korea...
