Summary of Contents for Daewoo DASP800
- Page 1 DASP800 Paint gun USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INSTRUCTIONS ........................2 2. TECHNICAL DATA ........................... 4 3. EXPLANATORY DIAGRAM ........................5 4. VISCOSITY TABLE........................... 6 5. STARTING UP............................6 6. SPRAYING TECHNIQUE ......................... 8 7. TROUBLESHOOTING ........................... 10 WARRANTY ............................... 11... -
Page 3: Safety Instructions
8. Outdoor extension cable. When working outdoors only use approved and respectively marked extension cables. Safety instructions for DASP800 • Please read the operating instructions thoroughly and observe the safety instructions • Only coating materials such as paints, enamels, varnishes, etc, with a flash point of 21°C (32° in the United Kingdom) and above may be sprayed, without additional warming. - Page 4 • When working with the device DASP800 inside and outside care must be taken that no solvent vapors are sucked into the device. • When outdoors observe wind direction. When working indoors ensure that there is sufficient venti- lation. • Do not spray at the device.
-
Page 5: Technical Data
and the work to be performed • Have your power tool serviced by a qualified repair person using only identical replacement parts. • Forbidden to spray to the hatch of the the motor and etc. • When spraying normally, the motor should not be under the head of the gun and the container. 2. -
Page 6: Explanatory Diagram
Materials which can be used Solvent containing and water-dilutable enamel paints, vanishes, primers, two-component paints, clear enamels, motor-vehicle enamels, mordants and wood preservatives. Materials which cannot be used Wall paints (emulsions) etc., lyes and acid containing coating materials. 3. EXPLANATORY DIAGRAM 1 Air cap 2 nozzle 3 Union nut... -
Page 7: Viscosity Table
Therefore , use the viscosity table viscosity =thickness of the coating material page 9. Measuring the viscosity using the viscosity measuring cup 1. Thoroughly stir the coating material before starting measurement. 2. Immerse the viscosity measuring cup (contents 100cm3) completely in the coating material below rim level and allow to fill. - Page 8 Any position can be chosen for connection. 2. Unscrew the container from the spray gun . 3. Adjust the ascending pipe accordingly. It should be possible to spray the contents of the container leaving hardly any material left in the container.
-
Page 9: Spraying Technique
10. Adjust the spraying pattern and amount of material; set the amount of air and pressure, see- fig.8,9,10 and the description page 11. 11. Open trigger on the spray gun. Note : When the device is switch on the air will flow continually from the air cap. Adjusting the spray gun Choice of spraying effects A =vertical flat jet... - Page 10 Important: start spraying outside the surface to be sprayed and avoid stopping on the surface. Right (fig.11) Always hold the spray gun at an even distance of approx. 5-15cm from the object to be sprayed. Move the spray gun evenly across or up and down, depending on the adjusted spraying effect. An even movement of the spray gun will give a uniform surface quality Wrong (fig.12) Excessive paint mist formation uneven surface finish.
-
Page 11: Troubleshooting
7. TROUBLESHOOTING Remedy Problem Cause The nozzle is blocked. Clean No coating The ascending pipe is blocked. Clean material is The small hole in the ascending pipe is blocked. Clean coming out of Material adjustment screw turned too far to the Turn to the right (+) the nozzle left (-). -
Page 12: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
