Summary of Contents for Daewoo DASP 400
- Page 1 DASP 400 Paint gun USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INFORMATION .......................... 2 2. COMPONENTS ............................3 3. SETUP ..............................4 4. THINNING CHART ..........................5 5. CLEANUP ..............................8 6. MAINTENANCE ............................10 7. TROUBLESHOOTING ........................... 11 WARRANTY ............................... 13... -
Page 3: Safety Information
1. SAFETY INFORMATION • Read all safety information before operating the equipment. Save these instructions To reduce the risks of fire or explosion, electrical shock and the injury to persons, read and understand all instructions included in this manual. Be familiar with the controls and proper usage of the equipment. Indicates a hazardous situation which, if not avoided, could result in death or serious injury. -
Page 4: Components
• Do not spray outdoors on windy days. • Wear protective clothing to keep paint off skin and hair. • Never aim spray gun at any part of the body. Household use only. Intended for outdoor use ONLY with materials having flashpoint above 70ºF (21ºC). -
Page 5: Setup
3. SETUP 1. Turn both knobs on both sides of the Air Compressor Assembly to the “Unlock” position, and Insert the spray gun into the Air Compressor Assembly into place, 2. Turn both knobs on both sides of the Air Compressor Assembly to the “Lock” position to lock the two pieces into place. -
Page 6: Thinning Chart
By pointing the suction tube in the proper direction, you will not have to refill the container as often.. Material Preparation Before spraying, the material being used may need to be thinned with the proper solvent as specified by the material manufacturer. Never exceed the thinning advice given by the coating manufacturer. - Page 7 Spraying The spray pattern shape is adjusted by turning the ears of the air cap to either the vertical, horizontal, or diagonal positions. The positions of the air cap and the corresponding spray pattern shapes are illustrated below. Test each pattern and use whichever pattern is suitable for your appli- cation.
- Page 8 Proper Spraying Technique If spraying with an HVLP spray system is new or unfamiliar to you, it is advisable to practice on a piece of scrap wood or cardboard before beginning on your intended workpiece. Surface Preparation All objects to be sprayed should be thoroughly cleaned before spraying material on them. Areas not to be sprayed may, in certain cases, need to be masked or covered.
-
Page 9: Cleanup
Do not flex wrist while spraying. 4. CLEANUP Cleaning the Spray Gun Special cleanup instructions for use with flammable solvents (must have a flashpoint above 70ºF (21ºC): • Always flush spray gun outside. • Area must be free of flammable vapors. •... - Page 10 5. Attach the cup to the gun and plug in the sprayer. 6. Spray the solution through the gun for two seconds in a safe area. Spray again for two seconds. Unplug the spray gun, and trigger the spray gun so that the material inside the spray gun flows back into the container.
-
Page 11: Maintenance
11. (a) Clean the rear of the spray gun with the appropriate cleaning solution. (b) Turn the suction tube anti-clockwise and pull the suction tube downward to disassemble it from the spray gun. Then clean the suction tube with the appropriate cleaning solution. -
Page 12: Troubleshooting
6. TROUBLESHOOTING Problem Cause Solution A. Little or no material flow 1. Nozzle clogged. 1. Clean. 2. Suction tube clogged. 2. Clean. 3. Material volume setting 3. Increase volume setting (+). turned too low(-). 4. Suction tube loose. 4. Insert. 5. - Page 13 Number Part Description Quantity Sprayer Assembly Container Seal Suction Tube Seal Ring Suction Tube 2 Container Viscosity Cup Air Filter Air Compressor Assembly...
-
Page 14: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 15 Manufactured under license of Daewoo International Corporation, Korea...
