Summary of Contents for Daewoo DALPG18-1
- Page 1 DALPG18-1 Lithium spray gun USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INSTRUCTIONS ........................2 2. READ ALL INSTRUCTIONS ........................4 3. TECHNICAL SPECIFICATIONS ....................... 5 4. ASSEMBLY ............................... 7 5. CLEANUP ............................... 11 6. SPARE PARTS LIST AND EXPLODED VIEW ..................12 WARRANTY ............................... 14... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS Definitions: Safety words This instruction manual uses the following safety words to alert you to hazardous situations and your risk of personal injury or property damage. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. - Page 4 • REMOVE BATTERY – when not in use, or prior to cleaning. • AVOID DANGEROUS ENVIRONMENTAL CONDITIONS – Do not use electric appliances in damp or wet locations. Follow all instructions in this Instruction Manual for proper operation of your applian- ce.
-
Page 5: Read All Instructions
• Do not charge appliance in rain, or in wet locations. WARNING: Do not use appliance if the switch trigger does not turn the appliance on or off. Any appliance that cannot be controlled with the switch trigger is dangerous and must be repaired. WARNING: Some dust created by this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. -
Page 6: Technical Specifications
persist, seek medical attention. WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame. WARNING: Fire hazard. Never attempt to open the battery pack for any reason. If the battery pack case is cracked or damaged, do not insert into the charger. Do not crush, drop or damage the battery pack. - Page 7 Spray width lever Adjustment ring Variable speed trigger Battery pack Adjustment ring: The spray pattern shape is adjusted by turning Horizontal pattern the adjustment ring to (use “up and down” either the vertical or spraying motion). horizontal positions. Spray width lever: The spray width lever determines the width of the spray pattern.
-
Page 8: Assembly
4. ASSEMBLY Before you begin: NEVER point the spray gun at any part of the body. To Assemble: IMPORTANT: Make sure the power cord is unplugged. 1. Insert the suction tube into the intake opening. 2. Align the suction tube - a. - Page 9 • For thinner materials, it is recommended that you start with a low material flow setting, and then gradually increase the flow to suit your particular spraying needs. • The higher the flow setting, the quicker you will have to work in order to avoid drips and sags in your spray pattern.
- Page 10 Tips: 1. Start with a fan pattern for painting trim work (1-5” width) and larger surfaces like doors and walls (>5” width). 2. Adjust Material & Air Flow settings as shown in chart based on coating, fan pattern width, and nozzle.
- Page 11 • Always apply a thin coat of material on the first pass and allow to dry before applying a second, slightly heavier coat. • When spraying larger surfaces, overlap each spray pass by at least 50% This will ensure full coverage.
-
Page 12: Cleanup
spray gun further away from the surface. NOTE: If after following the guidelines on these two pages you are still not getting the spray perfor- mance you need, refer to the 'Troubleshooting’ section on page 15. Besides adjusting the controls, other factors that should be considered when spraying: •... -
Page 13: Spare Parts List And Exploded View
1. Make sure power cord is unplugged. Push the tab below the trigger, twist and separate the nozzle from the turbine. Wipe the exterior of the cup and nozzle until clean. 2. The nozzle only - a. Remove the adjustment ring carefully from the connecting nut. Loosen the connecting nut. b. -
Page 15: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 16 Manufactured under license of Daewoo International Corporation, Korea...
