Summary of Contents for Daewoo DASP500
- Page 1 DASP500 Paint gun USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INSTRUCTIONS ........................2 2. SAFETY INSTRUCTIONS FOR DASP500 ....................2 3. TECHNICAL DATA ..........................4 4. EXPLANATION OF THE SYSTEM ......................4 5. FUNCTION DESCRIPTION ........................5 6. EXPLANATOYRY DIAGRAM ........................5 7. VISCOSITY TABLE ..........................6 8. -
Page 3: Safety Instructions
8. Outdoor extension cable When working outdoors only use approved and respectively marked extension cables. 2. SAFETY INSTRUCTIONS FOR DASP500 • Please read the operating instructions thoroughly and observe the safety instructions • Only coating materials such as paints, enamels, varnishes, etc, with a flash point of 21°C (32° in the United Kingdom) and above may be sprayed, without additional warming. - Page 4 • When outdoors observe wind direction. When working indoors ensure that there is sufficient ventilation. • Do not spray at the device. • The device only splash-proof when the air hose is correctly connected. • Do not let children play with the device. Keep out of reach of children. •...
-
Page 5: Technical Data
• Forbidden to spray to the hatch of the the motor and etc. • When spraying normally, the motor should not be under the head of the gun and the container 3. TECHNICAL DATA Voltage/Frequency: 110V~60Hz 220-240V~50-60Hz Power: 500 W Max working pressure: 0.1 ~ 0.2 bar Flow rate: 200 ml/min Mains cable: 2 m... -
Page 6: Function Description
5. FUNCTION DESCRIPTION The motor blower produces a flow of air which flows through the air hose to the spray gun. The air flow atomizes the coating material at the nozzle and also pressurizes the container. This pressure pushes the coating material up the ascending pipe to the nozzle. The air and pressure setting can be adjusted progressively. -
Page 7: Viscosity Table
Measuring the viscosity using the viscosity measuring cup 1. Thoroughly stir the coating material before starting measurement. 2. Immerse the viscosity measuring cup (contents 100cm3) completely in the coating material below rim level and allow to fill. 3. ift the viscosity measuring cup and measure the time in seconds until the flow of coating material stops. -
Page 8: Starting Up
FIG. 5 8. STARTING UP Any position can be chosen for connection. 2. Unscrew the container from the spray gun . 3. Adjust the ascending pipe accordingly. It should be possible to spray the contents of the container leaving hardly any material left in the container. -
Page 9: Adjusting The Spray Gun
9. ON/OFF switch on the device. 10. Adjust the spraying pattern and amount of material; set the amount of air and pressure, see- fig.8,9,10 and the description page 11. 11. Open trigger on the spray gun. Note : When the device is switch on the air will flow continually from the air cap 10. - Page 10 Important: start spraying outside the surface to be sprayed and avoid stopping on the surface. Right (fig.11) Always hold the spray gun at an even distance of approx. 5-15cm from the object to be sprayed. Move the spray gun evenly across or up and down, depending on the adjusted spraying effect. An even movement of the spray gun will give a uniform surface quality Wrong (fig.12) Excessive paint mist formation uneven surface finish...
-
Page 11: Troubleshooting
Note: Never clean the nozzle or air hole of the spray gun with sharp metallic objects. 12. TROUBLESHOOTING Troubleshooting Remedy Problem Cause The nozzle is blocked. Clean No coating The ascending pipe is blocked. Clean material is The small hole in the ascending pipe is blocked. Clean coming out of Material adjustment screw turned too far to the... -
Page 12: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
