IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C.
power is supplied to the unit.
CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
2.
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and by discon-
necting the unit connector.
CAUTION – This is a sealed unit. The integral, high temperature Ni-Cad battery is not replaceable. Replace
3.
the entire unit when necessary and recycle or dispose of the nickel-cadmium battery properly.
4.
DO NOT USE OUTDOORS. The I-42-EM-TM is for use with grounded, UL Listed, indoor fixtures. Not for use
in heated air outlets or hazardous locations.
5.
The I-42-EM-TM requires an unswitched A.C. power source of either 120 or 277 volts. Properly cap the un-
used A.C. lead.
When the I-42-EM-TM is installed on the same branch circuit, refer to Illustration 2, Figures A and B for input
6.
wiring. When installed on separate branch circuits, refer to Illustration 2, Figures C and D for input wiring. Per
NEC, the I-42-EM-TM and A.C. ballast must be on the same panel board.
7.
Do not mount near gas or electric heaters.
The I-42-EM-TM should be mounted in locations and at heights where it will not readily be subjected to tam-
8.
pering by unauthorized personnel.
9.
The I-42-EM-TM will cold strike and operate one 10W through 42W, or two 10W through 18W, 4 pin Rapid
Start compact fluorescent lamps. Contact Customer Service for additional lamp usage.
10.
The I-42-EM-TM is compatible with most electronic A.C. ballasts (including multiple lamps) as follows:
Electronic ballasts – one or two lamp emergency operation.
11.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
12.
Do not use this equipment for other than intended use.
13.
Install in accordance with the National Electrical Code and local regulations.
14.
Installation and servicing should be performed by qualified personnel.
15.
Lighting fixture manufacturers, electricians, and end users need to ensure product system compatibility before
final installation.
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS
I-42-EM-TM
TBTS SERIES AC
10W–42W RAPID START
4 PIN COMPACT LAMP
EMERgENCY LIgHTINg EqUIPMENT
THIS UNIT CONTAINS A
RECHARGEABLE NICKEL-
CADMIUM BATTERY. PLEASE
RECYCLE OR DISPOSE OF
PROPERLY.
Advertisement
Related Manuals for IOTA I-42-EM-TM
Summary of Contents for IOTA I-42-EM-TM
- Page 1 A.C. lead. When the I-42-EM-TM is installed on the same branch circuit, refer to Illustration 2, Figures A and B for input wiring. When installed on separate branch circuits, refer to Illustration 2, Figures C and D for input wiring. Per NEC, the I-42-EM-TM and A.C.
- Page 2 Compact 2. MOUNTING THE I-42-EM-TM Mount the I-42-EM-TM in the ballast channel or enclosed wireway so the wire leads are not exposed, at least ½″ away from the A.C. ballast(s). Refer to Illustration 1. When battery packs are remote mounted, the remote distance can not exceed ½ of the distance from ballast to lamp specified by the A.C.
- Page 3 Emergency Mode. One lamp or two lamps are illuminated, at reduced output, for a minimum of 90 minutes. When the A.C. power is restored, the I-42-EM-TM switches the system back to the Normal Mode and resumes battery charg- ing. See page 1 of the Instruction Manual.
- Page 4 � ORG (277V) VIOLET SWITCHED OR WHITE � VIOLET COMMON UNSWITCHED � LINE BLK/ORG OR BLK/BRN � EMERGENCY RED OR RED/BLK(+) I-42-EM-TM � BLK/ORG OR BLK/BRN TBTS WHT/RED COMMON BALLAST BLUE BLUE WHT/BLK BLACK BLUE BLU/WHT � ONE LAMP WHT/BLK...
