Anybus
Wireless Bolt II
- Safety and Compliance Information
Technical Specifications
Model identification
AWB6BA
Communication connector
RJ45
Power connector
3-pole push-in spring connection
Power supply
Recommended: 12–24 VDC Reverse voltage protection
Min: 10 VDC
Max: 33 VDC
Max power: 2.5 W
Power over Ethernet (PoE)
IEEE 802.3af/802.3at Type 1 Class 3
Typical: 1.45 W
Max: 2.7 W
Voltage range: 37-57 V
Power consumption
Typical: 60 mA @ 24 V Max: 110 mA @ 24 V
Antenna
MIMO 802.11 a/b/g/n and 802.11ac
Wireless LAN
2.4 GHz, channel 1-11 + 12-13 depending on regulatory domain scan
5 GHz Access Point: 36-48 (U-NII-1)
5 GHz Client: 100-116 + 132-140 and 120-128 (U-NII-1, U-NII-2,
U-NII-2e) depending on regulatory domain scan
RF output power: 18 dBm
Storage temperature
-40 to +85 °C
Operating temperature
-25 to +65 °C
Humidity
EN 600068-2-78: Damp heat, +40°C, 93% humidity for 4 days.
Vibration
See datasheet
Housing material
Plastic (see data sheet for details)
Aluminum (see data sheet for details)
Protection class
Top (outside of host): IP66 / UL Type 4X
Base (inside of host): IP30
Product weight
284 g
Dimensions
113 x 59 x 113 mm (W x H x D)
Mounting
M50 screw and nut. 50.5 mm hole needed.
Additional technical data and information related to the installation and use
of this product can be found at www.anybus.com/support.
CE Compliance
This product is in compliance with the EMC Directive 2014/30/EU and
the RoHS Directive 2011/65/EU with amendment 2015/863 through
conformance with applicable standards. The full text of the Declaration of
Conformity is available at www.anybus.com/support.
UKCA Compliance
This product is in compliance with the Electromagnetic Compatibility
Regulations 2016. The full text of the Declaration of Conformity is available
at www.anybus.com/support.
Disposal and Recycling
You must dispose of this equipment properly according to local laws and
regulations. Because this equipment contains electronic components, it must
be disposed of separately from household waste. When this equipment
reaches its end of life, contact local authorities to learn about disposal and
recycling options, or return the equipment to HMS. For more information,
see www.hms-networks.com.
UL Ordinary Locations (OrdLoc)
This equipment is certified for use in ordinary locations in compliance with
the following standards:
• UL 61010-1 SAFETY REQUIREMENTS FOR ELECTRICAL EQUIPMENT FOR
MEASUREMENT, CONTROL, AND LABORATORY USE - PART 1: GENERAL
REQUIREMENTS
• UL 61010-2-201 STANDARD FOR SAFETY REQUIREMENTS FOR ELECTRICAL
EQUIPMENT FOR MEASUREMENT, CONTROL, AND LABORATORY USE -
PART 2-201: PARTICULAR REQUIREMENTS FOR CONTROL EQUIPMENT
• CSA C22.2 NO. 61010-1-12 SAFETY REQUIREMENTS FOR ELECTRICAL
EQUIPMENT FOR MEASUREMENT, CONTROL, AND LABORATORY USE. PT.
1, GENERAL REQUIREMENTS
• CSA C22.2 NO. 61010-2-201:14 SAFETY REQUIREMENTS FOR ELECTRICAL
EQUIPMENT FOR MEASUREMENT, CONTROL, AND LABORATORY USE -
PART 2-201: PARTICULAR REQUIREMENTS FOR CONTROL EQUIPMENT
The certification number for the OrdLoc certified equipment is: E214107
According to the standards listed above, the equipment is certified with the
following marking:
© 2023 HMS Networks
Box 4126, 300 04 Halmstad, Sweden
SP3091 / Publication date 2023-03-20
