Using MaestroZ
1. Make sure the Management Platform is powered and is working correctly.
2. Download the latest software from the ZeeVee website. Make note of the location of
where the software was downloaded.
3. Login to the Maestro Z. Refer to Accessing Maestro Z (page 12)
tion.
4. Click the Server option at the left of the page.
5. Scroll down within the Server pain until you see the option to Update Server
Software. Drag the latest software into the box and press Update Server to begin
process.
Commands
for more informa-
134

Specifications

CPU
Operating System
Internal Storage
Graphics
LAN
Internal Memory
Power Supply
Rear I/O
Operating Temperature
Storage Temperature
VESA
Dimensions (W x H x D)
RoHS
Appendix
• Intel® Celeron® Processor 3205U
• Linux Ubuntu 14.04
• 64 GB SSD
• Intel® HD Graphics
• Gigabit LAN (Realtek RTL8111G)
• 8 GB
• Input: 100 ~ 240 V AC
• Output: 19 V DC, 3.42 A
• 1 x Type A, 19-pin female
• 1 x Mini DisplayPort, 20-pin, female
• 4 x USB 3.0, Type- A, female
• 1 x RJ45
• 1 x 5V DC
• 1 x Kensington lock slot
• 0 ºC to +35 ºC
• -20 ºC to +60 ºC
• VESA Bracket included
Supports 75 x 75 and 100 x 100 mm
• 4.25 in x 1.33 in x 4.5 in
(107.9 mm x 33.8 mm x 114.3 mm)
