flash-leds
Physically identifies the specified device on the network. When this command is executed,
the fiber LED indicators on the device will flash for 5 seconds.
Syntax
flash-leds id
Parameters
id
Type: STRING or MAC Address
The name or MAC address of the device. String names are case-sensitive.
Example
flash-leds myEncoder
Success
flash-leds 0:1e:c0:f6:59:13
Success
Advanced Operation
66
join
Joins the specified decoder (display) with the specified encoder (source). The mode
parameter must be specified and defines the type of join to execute.
► analog-audio
Embeds audio stream from the encoder on the output of the decoder. The audio can
be from the HDMI input or from the (analog) Audio jack on the encoder.
In order to control what type of audio is being sent from an encoder, refer to the set
device command.
► fast-switched
Allows the joining of an encoder and decoder with no video dropout. In order to make
use of this feature, the resolution and frame rate of the "new" encoder must be the
same as the previous encoder.
► genlocked
This mode provides a very low-latency, all-purpose method of joining an encoder and
decoder.
► hdmi-downmix-audio
Embeds hdmi-downmix audio from an encoder to specified decoder.
► multiview
Join the configured multiview to a display (decoder)
► usb
Creates USB connection between encoder and decoder. Note that mulitple
connections are valid.
Syntax
join enc dec mode
Parameters
enc
Type: STRING or MAC Address
The name or MAC address of the encoder. String names are case-sensitive.
dec
Type: STRING or MAC Address
The name or MAC address of the decoder. String names are case-sensitive.
