Selecting MADI High Speed/Non-SMUX
2
Whether to use SMUX mode or High Speed (a.k.a non- SMUX
long as both devices have the same setting. For our example configuration we could leave the MadiXtreme and Alpha-Link
set to their default, which is SMUX
However, setting both of them to High Speed is preferable, as it will allow the Alpha-Link to correctly interpret changes in
the Sample Rate made from the DAW computer, in the TRack software (PC) or in the MadiXtreme Preferences (Mac), when
a low sample rate is selected.
While the Alpha-Link is still in Diagnostics mode, follow the steps below:
1) Page 1 should already be selected (LED 17 lit). Keep that selection.
2) Press the OUTPUT button to select Option 2 (indicated by LED 10 being lit in the Metering section).
3) Press the INPUT button to change the connection mode (LED 2 will be turned off ).
Press
2 mode
2 .
Press
Page 5
2
) mode when working at high sample rates is not critical, as
Option 2 selected
Option 2 status
changed
