Summary of Contents for Solid State Logic A16.D16
- Page 2 As research and development is a continual process, Solid State Logic reserves the right to change the features and specifications described herein without notice or obligation. Solid State Logic cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in this manual.
-
Page 3: Table Of Contents
A16.D16, A32 and D64 User Guide Contents Table of Contents Appendix A – Physical Specifications Introduction Ventilation Overview Key Features Appendix B - Connector Pin Outs A16.D16 Front Panel Analogue Inputs/Outputs A16.D16 Rear Panel AES/EBU Inputs/Outputs A32 Front Panel GPIO (A16.D16 Only) A32 Rear Panel Appendix C –... -
Page 4: Introduction
25-pin D-type. These units can all be controlled remotely from SSL System T and SSL’s Network I/O Controller app for PC. A16.D16 is a 32-input and 32-output Dante I/O device featuring 4 SuperAnalogue mic/line inputs, 12 SuperAnalogue line inputs, 8 AES3 inputs, 16 SuperAnalogue line outputs, 8 AES3 outputs and 4 GPIO connections. -
Page 5: A32 Front Panel
A16.D16, A32 and D64 User Guide Contents A32 Front Panel A32 Rear Panel D64 Front Panel D64 Rear Panel Page 5 of 26... -
Page 6: Status Leds And User Buttons
A16.D16, A32 and D64 User Guide Contents Status LEDs and User Buttons Status and Reset These reset buttons have the same functionality as the front-facing RESET A and RESET B user buttons. Device Reset Performing a device reset will clear the SSL device settings. This includes ownership, input and GPIO states. - Page 7 A16.D16, A32 and D64 User Guide Contents User and Control Bit Pass-Through (A16.D16 and D64 only) To enable the pass-through of AES user and control bits the device must be set to PCM 32 encoding within Dante Controller. Changing the encoding setting is detailed in the Dante Controller section of this guide.
-
Page 8: Hardware Connections
Dante Connections The A16.D16, A32 and D64 have two redundant sets of network connections. The Network B port connectivity is currently not enabled, this requires an additional Dante card which is currently not available. Audio and GPIO Connections ... -
Page 9: Ssl Network I/O Controller
SSL Network I/O Controller Installing Network I/O Controller When an A16.D16, A32 or D64 is used without an SSL console, configuration and control is achieved using the SSL Network I/O Controller PC application. This can be downloaded from the SSL website as part of the Network I/O Stagebox upgrade package or as a standalone installer. -
Page 10: Network View
A16.D16, A32 and D64 User Guide Contents The GUI The application window is divided into six sections: Network View Page 10 of 26... -
Page 11: Inputs/Outputs
Select the Inputs, Outputs or AES I/O tab in the Page Select area to view I/O available on the network. Analogue Inputs This applies to the A16.D16 and A32 only. Mic/Line Inputs (A16.D16 Only) The following controls are available in the Focus window for A16.D16 inputs 9-12 only: Page 11 of 26... -
Page 12: Analogue Outputs
A16.D16, A32 and D64 User Guide Contents Analogue Outputs This applies to the A16.D16 and A32 only. The keys and combinations are mapped to the PC keyboard. For example, pressing ALT+UP on the keyboard will increase the gain by 3 dB. -
Page 13: Gpio (A16.D16 Only)
A16.D16, A32 and D64 User Guide Contents GPIO (A16.D16 Only) The A16.D16 is equipped with 4 GP input and 4 GP output circuits. Inputs are opto-isolated voltage triggered and output closures are via DIL relay. Appendix B for connector pinout and contact ratings. -
Page 14: Ownership
Input x ownership: control of input parameters on a per input basis ● N.B. Ownership settings are stored on the A16.D16/A32/D64. The mute state is stored in volatile memory on the unit and all channels will reset to unmuted if the unit is repowered. -
Page 15: Individual Input Ownership
Note that the audio route will still be made regardless of whether ownership is assigned. GPO Ownership (A16.D16 Only) The four A16.D16 GPO connections also have ownership status. The available ownership states are identical to those for inputs. Page 15 of 26... -
Page 16: Dante Controller
Network B functionality is not yet enabled. The Network Config tab within Dante Controller Device View allows for Networks A+B to be linked/unlinked, this currently has no functional effect on the unit. User and Control Bit Pass-Through (A16.D16 and D64 only) To enable the pass-through of AES user and control bits the device must be set to 32-bit encoding ( PCM 32 ). -
Page 17: Ventilation
A16.D16, A32 and D64 User Guide Contents Appendices Appendix A – Physical Specifications Parameter Value Notes Depth 460 mm (18.11") Height 88.5 mm (1.75") 2 RU Width 438 mm (17.25") Excluding rack ears 482 mm (19") Including rack ears Weight 9.5 kg (21 lb) -
Page 18: Appendix B - Connector Pin Outs
A16.D16, A32 and D64 User Guide Contents Appendix B - Connector Pin Outs Analogue Inputs/Outputs Location: Rear Panel Connector Type: 25-way D-type female Description Notes: Channel 8 (+ve) Same circuit arrangement for Inputs and Outputs. Channel 8 (–ve) Circuits offset by 8 for each addi onal connector. -
Page 19: Aes/Ebu Inputs/Outputs
A16.D16, A32 and D64 User Guide Contents AES/EBU Inputs/Outputs Location: Rear Panel Connector Type: 25-way D-type female Description Notes: Out channels 7/8 + Outputs. Out channels 7/8 - Circuits offset by 8 for each addi onal connector. Ground Out channels 5/6 +... -
Page 20: Gpio (A16.D16 Only)
A16.D16, A32 and D64 User Guide Contents GPIO (A16.D16 Only) GP Outputs All output switch closures are via DIL relay. DO NOT use these outputs to directly switch capacitive or reactive loads; always use a separate external relay with suitable contact rating. -
Page 21: Mic/Line Inputs
A16.D16, A32 and D64 User Guide Contents Appendix C – Performance Specifications Mic/Line Inputs Parameter Value Notes +26 to +70 dB Mic mode, 0 dBFS, 0.1 dB gain step size Gain Range -4 to +30 dB Line mode, 0 dBFS, 0.1 dB gain step size... -
Page 22: Line Inputs
A16.D16, A32 and D64 User Guide Contents Line Inputs Parameter Value Notes Maximum Input Level +24 dBu 10 kΩ load Frequency Response ± 0.1 dB -1 dBFS, 20 Hz – 20 kHz Usable Dynamic Range > 116 dB 0 dBFS, A-weighted filter, 22 kHz bandwidth Typically >117 dB... -
Page 23: Digital Inputs
A16.D16, A32 and D64 User Guide Contents Digital Inputs Parameter Value Notes Input Impedance 110 Ω Transformer coupled Sample Rates 44.1, 48, 88.2 176 kHz or 192 kHz with sample rate or 96 kHz converters enabled Sample Rate converters Selectable per AES channel pair... -
Page 24: Appendix D – Safety Notices
A16.D16, A32 and D64 User Guide Contents Appendix D – Safety Notices General Safety Please read and keep this document. Adhere to all warnings and follow instructions. This electrical equipment should not be used near water. Cleaning should only be with dry cloths or products compatible with electrical devices –... -
Page 25: Power Safety
A16.D16, A32 and D64 User Guide Contents Power Safety The unit is not supplied with a mains lead allowing you to use IEC distribution of mains cables of your choice. Any mains cable used must fulfill the following: Refer to the ratings label on the rear of the unit and always use suitable mains cords. -
Page 26: Environmental Declaration
RoHS Notice Solid State Logic has conformed and this product has conformed to European Union’s Directive 2011/65/EU on Restrictions of Hazardous Substances (RoHS) as well as the following sections of California law which refer to RoHS, namely sections 25214.10, 25214.10.2, and 58012, Health and...
