M M A A D D I I c c o o n n n n e e c c t t i i o o n n d d i i a a g g r r a a m m
The blue arrrows in the following diagram represent MADI connections made via simplex cables:
Alpha-Link MX 4-16
Alpha-Link MX 16-4
The MadiXtreme and Alpha-Links are are originally delivered with rubber dustcaps inserted in the MADI ports to
keep them clean (as shown in the diagram pictures). Pull these dustcaps out to gain access to the ports. We
recommend keeping these dustcaps, and replacing them whenever the ports are not in use.
Output side
MadiXtreme
(Pictured: MadiXtreme 128)
Alpha-Link MADI-SX
Input side
