Setting up the Alpha-Link as clock slave

Press the CLOCK button on the Alpha-Link's front panel, repeatedly if necessary, until the EXT LED is lit. The Alpha-Link will
now lock itself to the MADI-embedded clock reference signal received from the MadiXtreme, and follow sample rate
changes made in the TRack software (PC) or in the MadiXtreme Preferences (Mac).
The CLOCK LED should be lit solid to confirm lock. It will initially flash to indicate that the Alpha-Link MADI-SX is
not receiving a valid clock reference, until the MadiXtreme is correctly set as clock master, or after that if incorrect
settings have been selected for one of the devices. If it continues after all devices have been set up, try retracing
your steps to identify the problem. Do not switch on your monitoring system before you have rectified it.
Press
The EXT LED
should be lit
Page 8
