Canon imagePRESS C7011VPS Service Manual page 105

Canon
Table 69 – Booklet Trimmer-D1 Specifications
Item
Paper Size
Number of Sheets
Waste Tray Capacity
Conveyer Capacity
Electric Power Requirement From the Finisher / 300W Max (50/60 Hz)
Dimensions (D x W x H)
Weight
Table 70 – Two Knife Booklet Trimmer-A1 Specifications
Item
Paper Size
Number of Sheets
Trimming Width
Waste Tray Capacity
Conveyer Tray Capacity
Processing Speed
Electric Power Requirement
Dimensions (D x W x H)
Weight
imagePRESS C7011VPS/C6011VPS/C6011S Service Guide
Revision 3
imagePRESS C7011VPS/C6011VPS/C6011S Service Guide
Booklet Trimmer-D1
LTRR, 11"x17", LGL, 12"x18", 13"X19"
Up to 50 sheets (up to 80g/m
2
Up to 48 sheets (80 g/m ) + 2 sheets (325 g/m
Approximately 1,500 sheets of 20mm width trimmed piece
Up to 30 booklets
62.1" (W) x30.4" (D)x 41" (H) (1,575mm x 770mm x 1,040mm)
Approximately 335 lb (152kg)
Two-Knife Booklet Trimmer-A1
LTRR, 11"x17", LGL, 12"x18", 13"x19"
Up to 25 sheets/100 pages (16 to 20 lb. bond (60 g/m
Up to 15 sheets/60 pages (24 to 28 lb. bond (more than 80 g/m
Up to 5 sheets/40 pages (28 lb. bond to 110 lb Index (more than 105 g/m
2
g/m ))
Up to 4 sheets/16 pages (110 lb. index to 80 lb Cover (more than 209 g/m
2
g/m ))
Up to 1 sheet/4 pages (16 lb. Bond to 110 lb Cover (more than 209 g/m
2
g/m ))
Only one sheet of cover can be used up to 300 g/m
2-15mm (0.08" - 0.59")
*each width of top and bottom edge
*Minimum width of book in top and bottom direction; 190mm (7.48")
Approximately 1,500 sheets of 15mm width trimmed piece
Up to 30 booklets
(Same as the Booklet Trimmer-D1. Two-Knife Booklet Trimmer-A1 does not have
conveyer tray and uses conveyer tray of the Trimmer-D1.)
Follows the binding speed of the Finisher-AJ1/Saddle Finisher-AJ2
120-127volts, 50/60hz, 4A
Power consumption should not exceed 440W
30.3" (D)x 21.1" (W) x 40.9" (H) (770mm x 536mm x 1,040mm)
This does not include the dimension of the conveyer tray
It will add approximately 2" (5mm) in width when it is connected to the Booklet
Trimmer-D1
Approximately 320 lb (145 kg)
Specification
2
))
2
)
Specification
2
to 80 g/m
2
2
))
2 2
to 105 g/m ))
2
to 209
2
to 220
2
to 300
January 2015
Page 99
