Covered by one or more of the following US Patents: 10,451,235 / 10,371,333 / 10,520,149 / 10,731,810.
If you have any questions regarding the use of this unit or find that your fireplace/heater unit needs service, please do not return
the unit to the store where you purchased it. Instead, please contact our Customer Service Department and have your instructions
and parts list ready to provide the model name, part name, or factory number.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
HEATER DEFAULT SETTING:
The default factory setting for your thermostat is 82 degrees. If your room temperature is already 82 degrees
or above, then your heater will shut OFF after about 3 minutes. See thermostat directions for how to adjust
the temperature settings in order to keep your heater ON until your desired room temperature is reached.
We appreciate the trust and confidence you have placed in Whalen Furniture through the purchase of this electric fireplace/heater. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
COMBINATION ELECTRIC FIREPLACE/HEATER
Additional US and International Patents Pending
Model # WH100-23C2D-RD / WH100-23C2D-RDB
# WH100-26C2D-RD / WH100-26C2D-RDB
# WH100-30C2D-RD / WH100-30C2D-RDB
IMPORTANT
Whalen Customer Service
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our website www.whalenfurniture.com / www.whalenstyle.com
Or e-mail your request to: parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
improvement needs. Thank you for choosing Whalen Furniture Manufacturing!
Date: 2021-03-31
Quantum Flame and the Quantum Flame logo are
registered trademarks of Living Style (B.V.I.) Limited.
1-866-942-5362
THANK YOU
Rev 0001-C
LOT NUMBER:
DATE PURCHASED:
/
All rights reserved.
/
