Sim-Lab PUSH/PULL SHIFTER Instruction Manual page 5

Configuration
Depending on your setup, there might some configuration needed to make the PPS
fit your setup. We included 3 different ams to be able to adjust the positioning of the
paddle in relation to your wheel.
A6
A5
F
If arms (F) fitted out of the box need to be swapped, first rotate the lever (L) upwards
and loosen the nut (N). Now you can disconnect the complete shifter body along with
the arms and swap them with your preferred arms (A5/6).
With the new arms in place, some tweaking is still possible to suit your needs. When
re-assembling, don't tighten the nut (N) completely, the lever (L) will clamp down on
the system to tighten everything. When there is still play after you have clamped
down the lever, release the lever and adjust the tension of the nut and try again.
L
A
5
5 | 8
