Panasonic KV-S4065CL Specifications

Easy Maintenance
The clamshell design allows full, easy access
to the entire paper path, so you can clear paper
jams or clean the unit without calling a service
technician. The rollers are also easy to replace,
improving the unit's cost-effectiveness, and
have a long service life.
Rollers are easy to replace.
Specifications
KV-S4085CW/KV-S4085CL and KV-S4065CW/KV-S4065CL
KV-S4085CW KV-S4065CW
KV-S4085CL KV-S4065CL
Scanning Face Duplex
Contact-type Color Image Sensor
Scanning Method
Selectable black and white background reference
Up to 85 ppm (Portrait) Up to 65 ppm (Portrait)
Simplex
Up to 100 ppm (Landscape) Up to 80 ppm (Landscape)
Binary
Up to 170 ipm (Portrait) Up to 130 ipm (Portrait)
Duplex
Up to 200 ipm (Landscape) Up to 160 ipm (Landscape)
Scanning Speed * 1
Letter size 200/300 dpi
Up to 85 ppm (Portrait) Up to 65 ppm (Portrait)
Simplex
Up to 100 ppm (Landscape) Up to 80 ppm (Landscape)
Color
Up to 170 ipm (Portrait) Up to 130 ipm (Portrait)
Duplex
Up to 200 ipm (Landscape) Up to 160 ipm (Landscape)
Resolution 600 dpi Optical Resolution 100 - 600 dpi (1 dpi step)
Double feed detection (KV-S4085CW/KV-S4085CL: 3 positions,
Detection
KV-S4065CW/KV-S4065CL: 1 position), Stapled document detection
Compression JPEG (color, grayscale)
Binary, Grayscale (8 bit), Color,
Image Output
MultiStream™ output
Binary Mode Halftone Dither, Error diffusion
Dynamic Threshold, Automatic De-skewing, Automatic Crop,
Image Control Automatic Binary/ Color Distinction, Blank Page Removal,
Double Exposure, Multi Color Dropout, Smooth Background,
Executed by driver software or
Hole Removal, Border Removal, Noise Reduction,
Panasonic RTIV™
Detect File Separation Sheet and much more
Length control, Barcode detection (ISIS), Patch code detection,
Other Functions
Automatic separation, Control sheet, Long paper mode
100 feet (30,480 mm)
Long Paper Mode
(crop pages to maximum 100 in. (2,540 mm) per page)
KV-S4065CL / KV-S4085CL: 8.9 in. x 100 in. (227 mm x 2,540 mm)
Scanning Size
KV-S4065CW / KV-S4085CW: 11.9 in. x 100 in. (302 mm x 2,540 mm)
1.9 in. × 2.75 in. (48 mm × 70 mm)
Minimum
In manual feed or thick paper modes: 1.9 in. × 3.9 in. (48 mm × 100 mm)
Size (ADF)
Maximum 11.7 in. × 17 in. (297 mm × 432 mm)
Thin mode: 5 - 13 lbs. (20 - 50 g/m 2 )
Normal mode: 13 - 42 lbs. (50 - 157 g/m )
2
Documents * 2 Weight
Thick mode: 42 - 56 lbs. (157 - 209 g/m 2 )
Auto mode: 5 - 42 lbs. (20 - 157 g/m 2 )
1.9 - 7.9 mils (0.04 - 0.2 mm)
Straight path: max. 23.6 mils (0.6 mm)
Thickness
Note: 1 mil = 0.001 in.
Hopper Capacity Up to 300 sheets (17 lbs., 64 g/m 2 )
Interface USB 2.0
Power Requirement AC 100 - 240 V, 50/60 Hz
ENERGY STAR ® and the ENERGY STAR certification marks are registered US marks.
MultiStream™, ISIS ® and ISIS-Certified™ are trademarks of Pixel Translations, a division of EMC Corporation.
All other brand or product names are the property of their respective holders. Design and specifications are subject to change without notice.
Panasonic Communications Company of North America
One Panasonic Way, Secaucus, NJ 07094
www.panasonic.com/scanners
The clamshell opens widely.
KV-S4085CW KV-S4065CW
KV-S4085CL KV-S4065CL
Maximum (Scanning) 1.5 A 1.4 A
Power
Minimum (Standby) 0.7 A 0.7 A
Consumption
Sleep mode 4 W or less 4 W or less
Temperature 59 °F - 86 °F (15 °C - 30 °C)
Operating
Environment
Humidity 20 - 80 % RH
Temperature 32 °F - 104 °F (0 °C - 40 °C)
Storage
Environment
Humidity 10 - 80 % RH
18.7 in. x 23.0 in. x 13.0 in.
External Dimensions * 3 (W x D x H)
(474 mm x 585 mm x 329 mm)
Weight * 3 55 lbs. (25 kg)
CD ROM : Operation manual, Installation manual,
RTIV™ manual, PIE manual,
User Utility manual, Control data sheet,
Accessories
RTIV™ capture software, ISIS ® / TWAIN driver
software, User utility software, Multi color dropout utility
Power cord, USB cable & Blower
Roller exchange kit KV-SS033
Roller cleaning paper KV-SS03
Options
Imprinter unit (Pre and/or Post) KV-SS014
Ink cartridge KV-SS021
*1 The scanning speed differs depending on the host computer, operating system, application,
image data amount, and paper type.
*2 "Weight in pounds" of paper represents the weight of 500 sheets (17 in. × 22 in. / 432 mm × 559 mm).
*3 Dimensions and weights are approximate.
Dimensions
23.0 in.
(585 mm)
18.7 in.
(474 mm)
®
As an ENERGY STAR Partner,
Panasonic has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
KV-S4085/4065C BR 4/08
Smart!
Color Document Scanner
KV-S4085CW/KV-S4085CL ・ KV-S4065CW/KV-S4065CL
Innovative Paper Feed Mechanism
- Stapled Document Detection
- Ultrasonic Double-Feed Detection
- Intelligent Feed Control
. Mixed Document Feeding
. Long Paper Mode
(Curved or Straight Path)
. 100 ppm / 200 ipm
* (KV-S4085CW/KV-S4085CL)
80 ppm / 160 ipm
* (KV-S4065CW/KV-S4065CL)
* Letter, Landscape, 200/300 dpi, Binary/Color
13.0 in.
(329 mm)
