PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS
PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD
RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
Contact your building or fire officials about restrictions and installation inspection
requirements in your area.
WARNING:
Improper installation, adjustment, alteration, service
or maintenance can cause injury, property damage,
or loss of life. Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
IMPORTANT: SAVE THESE INSTRUCTIONS
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
920-585
Greenfire® GC60-2
TECHNICAL MANUAL
Freestanding Cast Iron Pellet Stove
Manuel en Français : https://bit.ly/3bzMqj0
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
French Manual: https://bit.ly/3bzMqj0
FOR YOUR SAFETY:
09.22.22
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY Greenfire GC60-2
Summary of Contents for HAMPTON BAY Greenfire GC60-2
- Page 1 Greenfire® GC60-2 TECHNICAL MANUAL Freestanding Cast Iron Pellet Stove French Manual: https://bit.ly/3bzMqj0 Manuel en Français : https://bit.ly/3bzMqj0 PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. Contact your building or fire officials about restrictions and installation inspection requirements in your area.
- Page 2 Safety Note: If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions, contact local building, fire officials, or authority having jurisdiction about restrictions and installation inspection requirements in your area. The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit.
-
Page 3: Table Of Contents
Table of Contents Safety Warnings & Recommendations....................4 Specifications..........................6 Rating Label & Location......................7 Dimensions..........................7 Specifications...........................7 Installation ............................8 Deciding Where to Locate your Pellet Appliance................8 Removing Pellet Stove From Pallet.....................8 Clearances to Combustibles.......................9 Leveling Leg Adjustment......................9 Thermostat Installation......................9 Vent Termination Requirements....................10 Outside Fresh Air Connection....................11 Exhaust And Fresh Air Intake Locations..................11 Mobile Home Installation......................12 Corner Through Wall Installation....................12... - Page 4 Safety Warnings & Recommendations *This manual is designed for the technician in conjunction with the owner’s manual.* Please read this entire Technical Manual before installing or operating your Hampton Pellet Stove. Failure to follow these instructions may result in property damage, bodily injury or even death. Any unauthorized modification of the appliance or use of replacement parts not recommended by the manufacturer is prohibited.
-
Page 5: Safety Warnings & Recommendations
Safety Warnings & Recommendations ELECTRICAL: The use of a surge protected power bar is highly recommended. The unit must be grounded. The grounded electrical cord should be connected to a standard 110-120 volts (4.2 Amps), 60 hertz electrical outlet and also must be accessible. If this power cord should become damaged, a replacement power cord must be purchased from the manufacturer or a qualified Hampton dealer. - Page 6 Safety Decal This is a copy of the safety label that accompanies each GC60-2. We have printed a copy of the contents here for your reference. On the GC60-2 the safety label is located on the underside of the hopper lid. See next page for location.
-
Page 7: Specifications
Specifications & l ating abel ocation Lift the cast top off the stove and place to one side. On the back of the pellet stove there will be two flat head screws that hold the hopper lid shut. Remove both screws. Once both screws have been removed open the hopper lid. -
Page 8: Dimensions
Specifications imenSionS 23" (584mm) 3” Fresh Air Intake 4” Exhaust 28-1/2" (724mm) 29-1/2" 28-12" (749mm) (724mm) 31-1/2" (800mm) 4” Exhaust 29" 18-3/4" (737mm) (476mm) Figure 2: Dimensions of GC60-2. pecificationS Input rating when using: Wood Pellets/Corn - 55,000BTU (16.1KW•hr) & Wheat/Barley - 53,000BTU (15.5KW•hr). Table 1: GC60-2 Specifications Description Fuel type... -
Page 9: Installation
Installation eciding here to ocate your ellet ppliance 1. Do not install the stove in a bedroom or room where people sleep in. 2. Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation. -
Page 10: Clearances To Combustibles
Installation learanceS to ombuStibleS These dimensions are minimum clearances but it Back Wall is recommended that you ensure sufficient room for servicing, routine cleaning and maintenance. 3" (76mm) Side wall to unit 9 inches (229 mm) Back wall to unit 3 inches (76 mm) Corner to unit... -
Page 11: Vent Termination Requirements
Installation ermination equirementS IT IS RECOMMENDED THAT YOUR PELLET STOVE BE INSTALLED BY AN AUTHORIZED DEALER/INSTALLER. Table 2: Use in conjunction with Figure 6 for allowable exterior vent termination locations. Letter Minimum Clearance Description 24 in (61 cm) Above grass, top of plants, wood, or any other combustible materials. 48 in (122 cm) Beside/below any door or window that may be opened. -
Page 12: Outside Fresh Air Connection
Installation utSide reSh onnection This Heater must have adequate air for proper combustion in the room that it is installed. A Fresh-air intake is strongly recommended for all installations. Failure to install intake air may result in improper combustion as well as the unit smoking during power failures. -
Page 13: Mobile Home Installation
Installation obile nStallation ● Secure the heater to the floor using the four (4) holes in the pedestal. ● Ensure the unit is electrically grounded to the chassis of your home (permanently). ● Do not install in a room people sleep in. -
Page 14: Horizontal Exhaust Through Wall Installation
Installation orizontal xhauSt hrough nStallation Vent installation: install vent at clearances specified by the vent manufacturer. A chimney connector shall not pass through an attic or roof space, closet or similar concealed spaces, or a floor, or ceiling. Where passage through a wall or partition of combustible construction is desired, the installation must conform to CAN/CSA-B365 Installation Code for Solid-Fuel-Burning Appliances and Equipment and with all local regulations, including those referring to regional and national. - Page 15 Installation 8. The pipe must extend at least 12” (30 cm) away from the building. If necessary, bring another length of pipe to the outside of the home to connect to the first section. Do not forget to place high temperature silicone around the pipe that passes through the thimble if required by vent manufacturer.
-
Page 16: Recommended - Through Wall With Vertical Rise And Horizontal Termination Installation
Installation recommended - t hrough ertical iSe and orizontal ermination nStallation Elbow with Screen or Termination Cap 4" 90 Wall framing Wall Strap A 45° down elbow with a screen may be used in place of the termination cap (or stainless steel Clean out Tee termination hood). -
Page 17: Outside Vertical Installations
Installation utSide ertical nStallationS To accomplish an outside vertical pipe installation, follow the “h ” OrizOntAl xhAust hrOugh nstAllAtiOns section and then finish it by performing the following (refer to Figure 15). 1. Install a tee with clean out on the outside of the house. 2. -
Page 18: Inside Vertical Installations
Installation nSide ertical nStallationS 1. Place the unit on the hearth pad if a hearth pad is to be used (or on solid material if installed on a carpeted surface) and space the unit in a manner so when the pellet vent is installed vertically, it will meet the minimum clearance from a combustible wall stated by the vent manufacturer. -
Page 19: Hearth Mount Installation
Installation earth ount nStallation Damper Removed or Fastened Open Mantel Minimum (8") 200mm from top of stove Clean-out tee Min (6") 150mm Fresh-air intake should com from chimney. If holes Floor already exist fresh-air intake can be taken through back Protection of the fireplace or through the ash dump. -
Page 20: Installations Only)
Top Vent Adaptor Kit & 4” (102 mm) to 6” (152 mm) Flue Adaptor (approved for vertical installations only) 4PVP-X6 4’’ (102 mm) pipe lengths to class A chimney GC60-920 *In order to achieve the maximum rated efficiency of 78% HHV purchase of a top vent adaptor kit (GC60-920) is required. Use the sheet metal screws provided to attach the kit to the rear of the unit as shown. -
Page 21: Slider/Damper Set-Up
Installation lider amper This is used to regulate the airflow through the pellet stove and has been set at the factory. C C o o n n v v e e c c t t i i o o n n F F a a n n Slider Removable Plate... -
Page 22: Troubleshooting
Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove from the firebox any screws without penetrating oil lubrication. WHAT TO DO IF: 1. - Page 23 Troubleshooting • Exhaust Temperature Sensor failure. Bypass sensor located on Exhaust Blower, if stove now operates properly, the unit may require cleaning or a new sensor. Contact your local dealer for service. • Check the agitator to make sure it is turning properly 3.
- Page 24 Troubleshooting 7. Light # 4 on Heat output bar flashing The 200 °F ( 93 °C) high limit temperature sensor has tripped. • Reset sensor and determine cause. Was it Convection Blower failure or Circuit board control problems? • Hopper lid has been left open for longer than two minutes. 8.
-
Page 25: Wiring Diagram
Wiring Diagram Black Brown 2µF Capacitor Black Exhaust Blue Combustion Temperature Brown Blower Blue Blue Sensor Black White 120V Ground Air Pump White Plug Green Ground Ignitor White Ground Thermostat White Agitator Blue/Yellow Black Motor White Auger Yellow Yellow Motor Purple Brown Blue... -
Page 26: Parts List
Parts List ITEM # DESCRIPTION PART # not shown Log Set (optional) GC60-930 not shown 120 CERAMIC EXHAUST TEMP SENSOR GF55-009 not shown WINDOW CHANNEL TAPE 72" GF55-018 not shown 5/8" DOOR GASKET 7' GF55-019 not shown PED & ASHPAN GASKET 10' GF55-020 not shown PELLET MECHANICAL &... - Page 27 GC60-2 Parts List ITEM # DESCRIPTION PART # AUGER BRASS BUSHINGS (2) GF55-045 FIRE GRATE GC60-013 AGITATOR DRIVE BRACKET GC60-067 AGITATOR DRIVE BRACKET ASSEMBLY C/W HARDWARE GC60-068 SS BURN POT LINER GC60-289 4" EXHAUST STARTER TUBE C/W GASKET GC60-040 AIR DEFLECTOR GC60-290 HOPPER SWITCH GC60-016...
-
Page 28: Parts Diagram - Components
GC60-2 Parts Diagram - Components Hampton GC60-2 Cast Pellet Stove Technical Manual... -
Page 29: Parts Diagram - Cast
Parts Diagram - CAST ITEM # DESCRIPTION PART # GC60 CAST FRONT - CHARCOAL GC60-201 GC60 CAST TOP - CHARCOAL GC60-211 GC60 CAST HOPPER LID - CHARCOAL GC60-221 GC60 CAST LEG - CHARCOAL GC60-231 GC60 CAST SIDE LEFT - CHARCOAL GC60-241 GC60 CAST SIDE RIGHT - CHARCOAL GC60-251... - Page 30 WARRANTY Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.
-
Page 31: Warranty
WARRANTY Replacement units are limited to one per warranty term. Airtube and baffle replacements are limited to one replacement per term. Unit must be installed according to all manufacturers’ instructions as per the manual. All Local and National required codes must be met. The installer is responsible to ensure the unit is operating as designed at the time of installation. - Page 32 WARRANTY Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 33 WARRANTY Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 34 WARRANTY Hampton GC60-2 Cast Pellet Stove Technical Manual...
- Page 35 Hampton GC60-2 Cast Pellet Stove Technical Manual...
- Page 36 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Regency, Hampton and Greenfire are registered and / or proprietary trademarks of FPI Fireplace Products International Ltd. ©...
