Select the training data that will be used to create the transform, the test data that will be used to
evaluate the transform, and additional test data (if any) that will also be used to evaluate the
transform.
•
Click Start to calculate the transform.
•
Click Export to save the transform, if desired.

4.3.5 ICC profile evaluation module

•
Load a raw camera image.
•
Click Select ICC profile directory... to show a list of profiles saved from the Color Transforms
module.
•
The color-managed image will be shown for viewing on an sRGB-calibrated display.
•
Export the color-managed image if desired.

4.3.6 Sample data set description

There is a set of sample data available on the USB drive. The images and text files can be used in all
modules to gain quick insight into the software. Explanation of the sample data:
•
Spectral Sensitivity (camSPECS) module, camSPECS XL folder:
XL_Calibration.txt – sample input calibration file for the camSPECS image. Not
o
applicable for customer's hardware.
o
camspecs.ARW– sample input raw capture of camSPECS filter plate.
camspecs_*.* – computed output spectral sensitivities saved in several formats.
o
•
Spectral Sensitivity (iQ-LED) module, iqLED folder:
SS_RGB.txt – sample input spectral sensitivity database.
o
o
Image folder - sample input folder of camera captures of the LEDs corresponding to the
contents of the Spectra folder.
o
Spectra folder - sample input folder of LED spectra saved from separate iQ-LED
software.
iQLED_specs.txt – sample computed spectral sensitivities output.
o
o
cameraPCs.txt, cameraRGBs.txt, LEDspectra.txt, sample output data files.
•
Validation module:
camspecs_specs.txt – computed spectral sensitivities output from the Spectral
o
Sensitivity module is the input for the Validation module.
ColorChecker.RW2 – sample raw capture of Color Checker illuminated with a D65
o
simulator.
•
Color Transforms module:
camspecs_specs.txt – computed spectral sensitivities output from the Spectral
o
Sensitivity (camSPECS) module is the Color Transforms profile creation module input.
o
camSPECS.icc - profile created from camspecs_specs.txt
o
iqLED.icc - profile created from iQ-LED_spectral.txt
