Appendices
Appendix B – Connector Details
XLR 3-Pin
Dimensions:
19 x 60mm (approx.)
Cable Dia:
5 – 12mm (typical)
Pinout for balanced audio:
Pin 1
Pin 2
Pin 3
180°
DIN 5-Pin
Dimensions:
15mm dia.
Cable Dia:
4mm - 7mm (typical)
Pinout as used for MIDI signals:
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Multipin
D-Type
25-way
Dimensions:
55 x 15mm (approx.)
Cable Dia:
8mm (typical)
1/4" TRS Jack
Pinout for balanced audio:
Tip
Ring
Sleeve
Duality SE Installation Guide
Screen/Ground
Hot (+ve)
Cold (-ve)
n/c
Screen
n/c
Midi +
Midi -
Hot (+ve)
Cold (-ve)
Screen
Plug
Socket
1
1
2
3
Connectors Viewed From Wiring Side
Socket
Plug
2
2
4
5
5
1
3
3
1
4
2
5
3
Connectors Viewed From Wiring Side
13
12
11
1
9
8
7
6
5
4
25
24
23
22
21
2
19
18
17
16
1
2
3 4
5
6
7 8 9 1
14 15 16 17
18 19 2
21
22 23 24 25
Stereo Plug
Tip
Ring
Sleeve
(T)
(R)
(S)
B – Connector Details
2
3
Connectors Viewed
4
From Wiring Side
1
3
Plug–Plug
5
2
MIDI Lead
4
1
3
2
1
Plug
15
14
11 12 13
Socket
Page 43
