Frosted Clamp-on Desk Privacy Panels (x2)
Instruction Manual
SKU: PP-2-G060C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/pp-2-g060c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo PP-2-G060C
Summary of Contents for Vivo PP-2-G060C
- Page 1 Frosted Clamp-on Desk Privacy Panels (x2) Instruction Manual SKU: PP-2-G060C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/pp-2-g060c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! ASSEMBLY STEPS If you do not understand these directions, or if you have any doubts about the safety of the STEP 1 installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product Separate Clamp (B) into three parts: Clamp Front (B1), Clamp Back (B2), and for any purpose that is not explicitly specified in this manual.
- Page 3 STEP 3 STEP 4b Place the Plastic Pads (D) on the inner face of Clamp Front (B1) and Clamp Back (B2) OPTION B: 1” - 2” (25mm - 50mm) Desktop Slide Back Clamp (B2) onto Lower Clamps (B3), and partially insert M6x25mm Screws (S-C) or M6x40mm Screws (S-D) depending on the desktop thickness.
- Page 4 STEP 5 STEP 7 Slide Front Clamps (B1) onto Back Clamps (B2). Insert the M6x12mm Screws (S-B) into the Front Clamps (B1), and tighten with Allen Wrench (T-A). STEP 6 Remove protective film from the Panels (A) place into the clamps, making sure the panels are fit between the plastic pads.
- Page 5 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
