- Page 1 ASSEMBLY INSTRUCTIONS DAYBED WITH CUSHIONS NOTE: 50% TIGHTEN BEFORE FIXING ALL BOLTS 300860 300861...
- Page 2 (1 x Bench) (1 x Stool) N otice : 1. 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. 2. Place the item on a flat ground to adjust and make sure it remains stable 3.
-
Page 3: Part List
Part List Arm Right Frame (1 pc) Arm Left Frame (1 pc) Bench Seat Frame (1 pc) Bench Back Frame (1 pc) Hip Back Frame (1 pc) Hip Back Frame (1 pc) Leg Right Stool (1 pc) Bench Back Side Frame (1 pc) Stool Seat Frame (1 pc) Stool Back Side Frame (1 pc) Leg Left Stool (1 pc) -
Page 4: Hardware List
Part List Bench Seat Cushion Stool Shelf Frame (1 pc) Stool Seat Cushion (1 pc) & Back Cushion (2 pcs) Back Pillow (2 pcs) Cover cloth (1 pc) Hardware List Bolt M6 x 30 mm Bolt M6 x 35 mm Bolt M6 x 40 mm 4 pcs + extra 1 pc 24 pcs + extra 2 pcs... - Page 5 CARTON CONTENT: 300860 C x 1 D x 1 E x1 F x 1 G x1 H x 1 K x1 L x1 M x1 N x 1 O x2 WF300861 A x 1 B x 1 I x 1 J x 1 P x 2 Q x 1...
- Page 6 STEP 1 (1 x Bench assembly) Connect Bench back frame (D) & Hip back frame (E), Hip back frame (F) with Bolts (1) & Washers (4), (6) D*1 E*1 STEP 2 Connect Arm left frame (B) & Bench seat frame ( C) & Bench back side frame (G) with Bolts (2), (3) &...
- Page 7 STEP 3 Connect part from Step 2 & part from Step 1 with Washers (7) part from Step 1 STEP 4 Connect part from Step 3 & Arm right frame (A) with Bolts (2), (3) with Bolts (2), (3) & Washers (4), (7)
- Page 8 STEP 5 Put on Bench Seat Cushion & Back Cushion (O) & Back Pillow (P) to complete Bench...
- Page 9 STEP 6 Connect Stool seat frame (H) & Leg right stool (I) & Stool back side frame (L) with Bolts (2) & Washers (4) L*1 H*1 I*1 STEP 7 Connect part from Step 6 & Leg left stool (J) with Bolts (2) & Washers (4)
- Page 10 STEP 8 Connect part from Step 7 & Stool Shelf frame (M) with Bolts (2) & Washers (4) STEP 9 Connect part from Step 8 & Stool Front side frame (K) with Bolts (2) with Bolts (2) & Washers (4), (5)
- Page 11 STEP 10 Put on Stool Seat Cushion (N) to complete Stool Take back frame down lowest and cover the product with Cover cloth (Q) when not in use...
- Page 12 Combination and Arrangement FINISH...
