- Page 1 ASSEMBLY INSTRUCTIONS FULL BED WITH BOOKCASE AND TRUNDLE WF295481/WF295482...
-
Page 2: Detail View
Detail View... -
Page 3: Part List
Part List Hardware List WF295481 Leg Left Front /Right Back- 2pcs Leg Left Back/Right Front - 2pcs Cap for lower - 2pcs Horizontal bar - 2pcs Horizontal bar - 4pcs Side rail - 2pcs Slats - 6pcs Slats - 4pcs... - Page 4 Part List WF295482 Side panel (left) - 1pc Side panel (right) - 1pc Upper shelf panel - 1pc Lower shelf panel - 1pc Middle shelf panel - 1pc Horizontal bar support - 1pc Upper divider panel - 2pcs Lower divider panel - 2pcs Upper back panel - 1pc Back panel (Left) - 1pc Back panel (Right) - 1pc...
- Page 5 Hardware List WF295481 8*30mm Wood dowel (2pcs) Hex-Head bolts (8pcs) Hex-Head bolts (12pcs) Hex-Head bolts (42pcs) Metal bracket (2pcs) Metal bracket (2pcs) 1/4"*15 (9.5mm) Hex-Head bolts (14pcs) Horizontal-Hole bolts(62pcs) Wood screws (50pcs) 100*63*20mm 70*35*19 mm Drawer stopper (2pcs) Wood screws (64pcs) Wheels (4pcs) (1/4")4.5*58mm...
- Page 6 STEP 1: 12PCS 12PCS Note:Part 8 will face up with the "x" mark on it, otherwise it cannot be tightened STEP 2: 6PCS...
- Page 7 STEP 3: 4PCS 2PCS Drawer stopper (10) with lower side rail front (F) by using screw (9). STEP 4: 8PCS 8PCS...
- Page 8 STEP 5: Assembling leg support (I) with lower support slat (H) later rotate, Move support slat inside Full bunkbed. STEP 6: 24PCS 5.4" 5.4" 2.5" 139mm 139mm 64mm Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges, otherwise it will cause the board to break.
- Page 9 STEP 7: 16PCS 16PCS STEP 8: 2PCS 16PCS 16PCS...
- Page 10 STEP 9: 4PCS STEP 10: 10PCS 10PCS...
- Page 11 STEP 11: 4PCS STEP 12: 18PCS...
- Page 12 STEP 13: 22PCS STEP 14:...
- Page 13 STEP 15: 8PCS 2PCS STEP 16: 8PCS 4PCS...
- Page 14 STEP 17: 14PCS 234mm Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges, otherwise it will cause the board to break. Do not lock the bed slats on the edge of the wood, please hold firmly before screwing , hold it in STEP 18: 8PCS...
- Page 15 STEP 19: 2PCS 8PCS STEP 20:...
- Page 16 STEP 21: Push Trundle and Drawer under the bottom of Bunkbed.
