- Page 1 ASSEMBLY INSTRUCTIONS TWIN/FULL BUNK BED WITH TRUNDLE AND DRAWER WF294409/WF294410/WF294411...
-
Page 2: Safety Warning
SAFETY WARNING 1. This bed is designed for use only mattress (es) meeting the following specifications on the upper bunk, and lower bunk: Upper bunk (Bunk bed and tribed included) Bed type Length Width Thickness Twin Standard 74"-75" 38 1/2" 6"... -
Page 3: Detail View
Detail View... -
Page 4: Part List
Part List WF294409 Side panel - 2pcs Leg (Left Front) - 1pc Leg (Left Back) - 1pc Lower side rail (front-back) - 2pcs Leg (Right Front) - 1pc Leg (Right Back) - 1pc Upper side rail (front-back) - 2pcs Long guard rail - 4pcs... - Page 5 Part List Hardware List WF294410 Cap for lower HB/FB - 2pcs Lower frame HB/FB - 2pcs Lower horizontal bar HB - 1pc Lower horizontal bar FB - 1pc Slat - 4pcs Slat - 10pcs Upper frame HB/FB - 2pcs Support drawer - 3pcs Drawer bottom - 3pcs Drawer bottom - 3pcs WF294411...
- Page 6 Hardware List WF294410 8*30mm Wood dowel (8pcs) Wood dowel (26pcs) Hex-Head bolts (24pcs) 60mm 40mm Hex-Head bolts (20pcs) Hex-Head bolts (38pcs) Hex-Head bolts (8pcs) 1/4"*15 (9.5mm) Wood screws (78pcs) Hex-Head bolts (6pcs) Horizontal-Hole bolts(82pcs) (1/4")4.5*58mm Allen key (2pcs) Hex-Head bolts (4pcs) Wood screws (8pcs) 400*30mm 3.5*19mm...
- Page 7 STEP 1: STEP 2: 12PCS 12PCS...
- Page 8 STEP 3: 8PCS 2PCS STEP 4: 4PCS...
- Page 9 STEP 5: 4PCS 2PCS Drawer stopper (20) with lower side rail front (I) by using screw (9). STEP 6: 8PCS 8PCS...
- Page 10 STEP 7: 2PCS 2PCS STEP 8: 32PCS 3.1 " 3.3 " 2.4 " 79mm 84.5mm 61mm Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges, otherwise it will cause the board to break. Do not lock the bed slats on the edge of the wood, please hold firmly before screwing ,...
- Page 11 STEP 9: 8PCS 8PCS STEP 10: 8PCS 16PCS 16PCS...
- Page 12 STEP 11: 6PCS STEP 12: 28PCS 3.1 " 3.3 " 2.4 " 79mm 84.5mm 61mm Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges, otherwise it will cause the board to break. Do not lock the bed slats on the edge of the wood, please hold firmly before screwing ,...
- Page 13 STEP 13: 4PCS STEP 14: 10PCS 10PCS...
- Page 14 STEP 15: 6PCS STEP 16: 8PCS 4PCS...
- Page 15 STEP 17: 2PCS 6PCS 6PCS STEP 18: 3PCS 3PCS...
- Page 16 STEP 19: 7PCS 7PCS STEP 20: 14PCS 36.5mm Note: Do not lock the screws of the bed slats to the outermost edge of the bed slats, you need to leave a certain space at the edges, otherwise it will cause the board to break. Do not lock the bed slats on the edge of the wood, please hold firmly before screwing ,...
- Page 17 STEP 21: 12PCS 6PCS 6PCS STEP 22: 12PCS 6PCS 6PCS...
- Page 18 STEP 23: 3PCS 9PCS STEP 24: Remark: When opening or closing the drawer, Please lift the drawer slightly before opening or closing it.
- Page 19 STEP 25: Push Trundle under the bottom of Twin bed.
