- Page 1 Assembly Instructions Mono kit...
-
Page 2: Table Of Contents
Amplifier & Supply Case 12mm Backpanel Cables Included: Lid & Frontpanel System information Troubleshooting & Support Warranty & Disclaimer Revisions Notes Parts Electronics EL-2 PS500DIY Nilai500DIY EL-1 EL-4 Mounting Plate EL-3 Switch EL-5 EL-6 EL-7 Terminal Control Front Control Back... - Page 3 Case CA-2 Side CA-3 Bottom CA-1 Feet Back CA-4 Front CA-5 Not used: CA-6 M3x7 Mounting set Case M4x10 M4x10 4.5mm MC-1 MC-2 MC-3 MC-4 4.5mm 4.3mm 3.3mm M3x5 M3x10 MC-5 MC-6 MC-7 MC-8 MC-9 MC-10...
- Page 4 Cable set CB-1 Z2B25L1 CB-2 CB-8 CB-5 CB-4 CB-6 CB-7 CB-9 CB-3 Mounting set 2.9X9.5 M3x6 M3x6 M3x6 MS-1 MS-3 MS-4 MS-2...
-
Page 5: Introduction
® Nilai 500 DIY Amplifier kit, a brief introduction Thank you for purchasing the Nilai 500DIY Amplifier ® This assembly instruction covers the general kit, powered by our Nilai technology. ® assembly instructions for this specific model. For detailed technical information about the used The Nilai amplifier and the Switch Mode Power Supply ®... -
Page 6: Safety Precautions
21. Changes or modifications not expressly approved by Hypex Electronics will void compliance and therefore the Utilisez une prise électrique mise à la terre pour cet user's authority to operate the equipment. -
Page 7: Assembly
Assembly Result:... -
Page 8: Amplifier & Supply
Amplifier & Supply M3x6 MS-3 EL-1 EL-2 M3x6 MS-4 CA-1 EL-3 CB-4 ❶ MS-4 ❷ MS-3 CA-1... - Page 9 ❸ Optional HIGH GAIN Read user instructions MID GAIN for details. LOW GAIN J200 Make sure no occational foil is placed. ❹ Optional Otherwise: remove the foil. ❺ MS-3 ❻ CB-4...
-
Page 10: Case
Case CA-3 CA-5 M3x10 3.3mm M4x10 4.5mm MC-8 MC-9 MC-1 MC-3 MC-4 ❶ MC-8 MC-9 ❷ MC-4 MC-3... -
Page 11: Backpanel
Backpanel CA-4 M4x10 MC-2 EL-4 CB-1 4.5mm CB-2 CB-3 T6.3A T6.3A 250V 250V MC-4 EL-5 2.9X9.5 CB-5 CB-6 MS-1 CB-7 EL-7 ❶ 100-240V~ 50-60Hz/650W ❷ PowerAmplifier | mono POWERED BY HYPEX ELECTRONICS LOUDSPEAKER LOUDSPEAKER TRIG INPUT FUSE T6.3AH/250V... - Page 12 ❸ ❹ ❺ 100-240V~ 50-60Hz/650W PowerAmplifier | mono POWERED BY HYPEX ELECTRONICS TRIG INPUT LOUDSPEAKER LOUDSPEAKER FUSE T6.3AH/250V ❻ ❼ ❽...
- Page 13 ❻ ❼ ❽ 100-240V~ 50-60Hz/650W PowerAmplifier | mono POWERED BY HYPEX ELECTRONICS LOUDSPEAKER LOUDSPEAKER TRIG INPUT FUSE T6.3AH/250V ❾ EL-7 MS-1...
- Page 14 CB-4 CB-5 CB-5 MC-4...
-
Page 15: Cables
MC-2 Cables M4x10 4.5mm 4.3mm MC-2 MC-5 MC-6 MC-7 ❶ ❷ ❸... - Page 16 ❹ CB-8 ❺ J103 CB-9 ❻ ❼ J100...
- Page 17 Front & Lid M3x5 MC-10 MS-2 EL-5 CA-5 ❶ ❷ ❸ EL-6...
- Page 18 CA-6 ❹ ❺ ❻...
-
Page 20: System Information
® System information Nilai 500 DIY Mono kit Line input power Dimensions and weight Line input voltage: 100 - 240Vac* External size (WxHxD): 205 x 80 x 300 mm Line input frequency: 47 - 63 Hz (size incl feet, excl connectors) Connector: 3-pin IEC 250Vac, 10A male. -
Page 21: Troubleshooting & Support
What kind of quality can I expect from this performance. DIY Amplifier kit? Use grounded wall sockets. Ÿ This kit contains Hypex Electronics Nilai® amplifier technology, currently this is Hypex Heat Electronics best sounding amplifier technology. The Amplifier Kit will get warm/hot when used Ÿ... -
Page 22: Warranty & Disclaimer
Date of purchase: Disclaimer Hypex Electronics BV, its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,“Hypex Electronics”), disclaim any and a l l l i a b i l i t y f o r a n y e r r o r s , i n a c c u r a c i e s o r... -
Page 23: Notes
Notes... - Page 24 ® DIYClassD.com Kattegat 8 9723 JP Groningen, The Netherlands +31 50 526 4993 sales@diyclassd.com www.diyclassd.com...
