FEATURES
• 3, 4, or 5 Megapixel Progressive Scan CMOS image sensors
• Up to 30fps live viewing
• Fixed, Varifocal, and Motorized Lens
• Infrared LED's with up to 150' IR Range
• Optional Advanced Starlight Technology Offers Dramatically Higher
Sensitivity to Light Producing Color Images in Very Dark & Night
Scenes (5 MegaPixel Versions)
• Digital Wide Dynamic Range (D-WDR)
• True Mechanical Day/Night function by ICR
• XD-DNR (2D-DNR & 3D-DNR) Noise Reduction
• On Board Motion Detection
• H.265/H.264/MJPEG Triple Streaming
• Secondary Video Output (CVBS)
• Remote Viewing via CMS, Internet Explorer, and iOS & Android
Apps
• Minimal Latency with up to 10 simultaneous user connections
• IP66 Weather Resistance
• MicroSD memory card slot for Local recording supporting up to
128GB MicroSDXC cards (Select Models)
• ONVIF Compliant
• Optional Mounts Available
• 12VDC & PoE (Power over Ethernet) Operation
PLEASE NOTE:
Documentation, Software, Tools, and Updates are available online.
Scan the QR Code or visit:
http://www.vitekcctv.com/Downloads
IP Camera Series
Transcendent Series 3, 4, and 5
Megapixel H.265 WDR IP Cameras
with IR LED Illumination

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRANSCENDENT VTD-TND3RVEB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vitek TRANSCENDENT VTD-TND3RVEB

  • Page 1 IP Camera Series Transcendent Series 3, 4, and 5 Megapixel H.265 WDR IP Cameras with IR LED Illumination FEATURES • 3, 4, or 5 Megapixel Progressive Scan CMOS image sensors • Up to 30fps live viewing • Fixed, Varifocal, and Motorized Lens •...
  • Page 2 Please read this manual carefully for correct use of the product. Notes Please use the specified power supply to connect. Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers. There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.
  • Page 3: Table Of Contents

    Table of Contents IE Remote Access ..................4 LAN ................4 1.1.1 Access through IP-Tool ..........4 1.1.2 Directly Access through IE ........6 WAN ................7 Remote Preview ..................8 The Remote Preview Interface ........8 Record Playback ............10 Snap Pictures ..............
  • Page 4: Ie Remote Access

    3.4.9 FTP ................. 27 Advanced Configuration ........... 28 3.5.1 User Configuration ..........28 3.5.2 Security Configuration ..........30 3.5.3 Configure Backup & Restore ........30 3.5.4 Reboot Device ............31 3.5.5 Upgrade ..............31 Q & A ....................... 33 1 IE Remote Access IP-CAM can be connected through LAN or WAN.
  • Page 5 gateway of the camera and make sure its network address is in the same local network segment as the computers. Modify the IP address of your device according to the practical situation. For example, the IP address of your computer is 192.168.13.4. So the IP address of the camera shall be changed to 192.168.13.X.
  • Page 6: Directly Access Through Ie

    1.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201 Subnet Mask: 255.255.255.0 Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time.
  • Page 7: Wan

    ② Open an IE browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control automatically. ③ After downloading Active X control, the login dialog box will pop up. ④ Input the default username and password and then enter to view. To access the camera via a router or virtual server: ①...
  • Page 8: Remote Preview

    Port Setup IP Setup Router Setup ④ Open IE browser and input its WAN IP and http port to access. 2 Remote Preview The Remote Preview Interface Remote Preview...
  • Page 9 Icon Description Icon Description Motion alarm Sensor alarm indicator icon indicator icon Fix size Start/Stop record Actual size Playback Zoom in Snap Zoom out Talk Full screen Enable audio When motion detection alarm is triggered, the people icon turns red. Right click to pop up a pull-down list as shown below: Stream: Three streams are available.
  • Page 10: Record Playback

    Button Description to rotate the dome upwards to rotate the dome downwards; to rotate the dome towards left; to rotate the dome towards right to rotate the dome diagonally up-left; to rotate the dome diagonally up-right; to rotate the dome diagonally down-left;...
  • Page 11: Snap Pictures

    Snap Pictures % Select the picture number and then click “Snap” icon as shown below. Single Snap % User can snap multiple pictures. Select the picture number from Frame pull down list box, such as 2, and check “Title” and “Time” to show capture title and time on the snap pictures simultaneously.
  • Page 12: Remote Configuration

    3 Remote Configuration Functions of remote configuration include: System Configuration, Video Configuration, Configuration, Alarm Configuration, Network Configuration Advanced Configuration. You should first select the menu on the left, and then set the relative parameters. System Configuration The “System configuration” includes two submenus: Basic Information and Date &...
  • Page 13: Sd Card

    2. Set time zone. 3. Enable DST mode as required. 4. Set time. You may set time manually or enable NTP. 3.1.3 SD Card . Go to “System Configuration” #“SD Card” as shown below: The first time you used the SD card, you should click “Format SD card”. Click “Eject card”...
  • Page 14: Camera Configuration

    3.2.1 Camera Configuration Setting steps: Go to “Video Configuration” # “Camera” interface as shown below. 2. You may adjust frequency, brightness, contrast, hue and saturation of the picture. 3. Select white balance mode. 4. Wide dynamic, sharpen and denoise are adjustable. 5.
  • Page 15 Bitrate type: CBR and VBR. CBR means that no matter how much the video changes, the compression bitrate keeps constant. This will not only facilitate the image quality better in a constant bitrate but also help to calculate the capacity of the recording. VBR means that the compression bitrate can be adjustable according to the changes in the video.
  • Page 16: Osd Configuration

    3.2.3 OSD Configuration 1. Go to “Video Config” # “OSD Config” menu to display the interface as shown below. You may set time stamp, device name and custom OSD here. Drag the time stamp and custom OSD to set their position. Then press the “Save” button to save the settings.
  • Page 17: Roi Configuration

    1. Enable video mask and select mask color. 2. Click “Draw” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to live view to see the following picture. Clear the video mask: Go to video mask menu and then click “Clear”...
  • Page 18: Alarm Configuration

    5. Click “Save” button to save the settings. You will see the selected ROI area is clearer than other areas especially in low bitrate condition. Alarm Configuration Alarm configuration includes seven submenus: Motion Detection Area, Motion Detection Trigger, Motion Detection Schedule, Alarm Input Trigger, Alarm Input Schedule, Alarm Out and Alarm Server.
  • Page 19: Motion Detection Trigger

    3.3.2 Motion Detection Trigger 1. Go to “Alarm Configuration” # “Motion Detection Trigger” to display an interface as shown below. 2. Check “Enable alarm” check box. Then all functions under this interface will be activated. 3. Set alarm holding time. 4.
  • Page 20: Motion Detection Schedule

    Note: Please refer to FTP configuration chapter for more details. 8. Press the “Save” button to save the settings. 3.3.3 Motion Detection Schedule Go to “Alarm configuration” # “Motion Detection schedule” interface as shown below. Week schedule User can set the alarm time from Sunday through Saturday for alarm everyday in one week.
  • Page 21: Alarm Input Trigger

    3.3.4 Alarm Input Trigger Enter “Alarm Configuration”# “Alarm Input Trigger” to see a screen as shown below: 2. Select the sensor at the “Sensor” pull down list and set the sensor name and alarm type: NO and NC. 3. Enable alarm and select alarm holding time. 4.
  • Page 22: Alarm Out

    3.3.6 Alarm Out 1. Go to “Alarm configuration”# “Alarm output” as shown below: 2. Select alarm holding time and alarm name at the “Alarm out” and “Alarm holding time” pull down list box respectively. 3. Press the “Save” button to save the settings. 3.3.7 Alarm Server Go to “Alarm configuration”# “Alarm Server”...
  • Page 23: Ip Address

    3.4.2 IP Address 1. Go to “Network Configuration”# “IP Address” to see the interface shown below. 2. There are two options for IP setup: obtain an IP address automatically by DHCP protocol and use the following IP address. You may choose one of the options as required.
  • Page 24: Ip Notify

    new device. Next, self-define the device ID and input the remaining information of the device in the CMS/NVMS. 3. Input the above-mentioned server IP, server port and device ID in the relevant boxes. 4. Click “Save” button to save the settings. 3.4.4 IP Notify 1.
  • Page 25 Create domain name. After you successfully request your domain name, you will see your domain in the list. 3. Select the server type and then input the username, password and domain name you apply for in the DDNS configuration interface. 4.
  • Page 26: Rtsp

    3.4.6 RTSP 4. Go to “Network Configuration”# “RTSP” interface as shown below. 5. 1. Select “Enable RTSP server”. 2. RTSP Port: Access Port of the streaming media. The default number is 554. 3. RTSP Address: The RTSP address you need to input in the media player. 4.
  • Page 27: Ftp

    1. From Email: Sender’s e-mail address. 2. User name and password: Sender’s user name and password. 3. Server address: SMTP name of sender. 4. Select the secure connection type at the Secure Connection dropdown list according to user’ actual needs. 5.
  • Page 28: Advanced Configuration

    Parameter Meaning Server name The name of the FTP server Server address The address of the FTP server Port The port number of the FTP server User name The user name of the FTP server Password The password of the FTP Advanced server Configuration...
  • Page 29 2. Clicking “Modify” button will pop up “Modify user” dialog box as shown below. Modify User 3. Input original password of this user in the “Password” text box. 4. Input new password in the “New password” and “Confirmation” text box. 5.
  • Page 30: Security Configuration

    3.5.2 Security Configuration 1. Go to Advanced Configuration#Security Configuration to see a tab shown below. 6. 2. Check “Enable IP address” check box, select “Deny the following IP address” input IP address in the IP address list box and click “Add” button.
  • Page 31: Reboot Device

    Default Configuration Click “Load default” button to restore all system settings to the default status. 3.5.4 Reboot Device Go to Advanced configuration—Reboot device to see an interface as shown below. Click “Reboot device” button to reboot the device. 3.5.5 Upgrade Go to Advanced Configuration—Upgrade interface as shown below.
  • Page 32 Set time: Select date in the “Calendar” and choose the start and end time. Choose event “Motion” or “Sensor”. Click “Search” button to search the picture. Double click a filename or select a filename and then click “View” button in the list box to view captured pictures.
  • Page 33 Item Buttons Explanations Close: Select certain picture and click this button to close this picture. Close all: Click this button to close all pictures viewing. Save: Click this button to select the save path of the picture file on the PC for saving the current picture. Save all: Click this button to select the save path of the picture files on PC for saving all pictures.
  • Page 34 Q IE cannot download ActiveX control? A. IE browser blocks ActiveX. Please do setup following below. Open IE browser. Click Tools-----Internet Options…. Select Security------Custom Level…. Enable all the sub options under “ActiveX controls and plug-ins”. Then click OK to finish setup. B.
  • Page 35 Detailed Specifications VTD-TND24R3F2 Image Sensor 1/3” 3.0 Megapixel Progressive Scan CMOS Image Size 3 MegaPixel 2304x1296 Resolution 3 MP (2304×1296) / 3MP(2048×1536)/1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night True Day/Night by ICR IR LEDs...
  • Page 36 Detailed Specifications VTC-TNB42R3F2 Image Sensor 1/3” 3.0 Megapixel Progressive Scan CMOS Image Size 3 MegaPixel 2304x1296 Resolution 3MP (2304×1296) / 2MP(2048×1536)/1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night True Day/Night by ICR IR LEDs...
  • Page 37 Detailed Specifications VTC-TNT2HR3F2 Image Sensor 1/3” 3.0 Megapixel Progressive Scan CMOS Image Size 3 MegaPixel 2304x1296 Resolution 3MP (2304×1296) / 2MP(2048×1536)/1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night True Day/Night by ICR IR LEDs...
  • Page 38 Detailed Specifications VTC-TNB36R3V2 Image Sensor 1/3” 3.0 Megapixel Progressive Scan CMOS Image Size 3 MegaPixel 2304x1296 Resolution 3MP (2304×1296) / 2MP(2048×1536)/1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.3~12mm (Vari-Focal) Day/Night True Day/Night by ICR IR LEDs IR Distance 120’...
  • Page 39 Detailed Specifications VTD-TND30R3V2 Image Sensor 1/3” 3.0 Megapixel Progressive Scan CMOS Image Size 3 MegaPixel 2304x1296 Resolution 3 MP (2304×1296) / 3MP(2048×1536)/1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.3~12mm (Vari-Focal) Day/Night True Day/Night by ICR IR LEDs IR Distance...
  • Page 40 Detailed Specifications VTD-TND24R4F2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night...
  • Page 41 Detailed Specifications VTC-TNB42R4F2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night...
  • Page 42 Detailed Specifications VTC-TNT2HR4F2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6mm Fixed Iris Lens Included (2.8mm Also Available) Day/Night...
  • Page 43 Detailed Specifications VTC-TNB48R4M2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens Motorized 3.3-12mm Day/Night...
  • Page 44 Detailed Specifications VTC-TNT2HR4M2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens Motorized 3.3-12mm Day/Night...
  • Page 45 Detailed Specifications VTD-TND30R4M2 Image Sensor 1/3” 4.0 Megapixel Progressive Scan CMOS Image Size 4 MegaPixel 2592x1520 Resolution 4 MP (2592x1520) / 3 MP (2304x1296) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens Motorized 3.3-12mm Day/Night...
  • Page 46 Detailed Specifications VTC-TNB48R5V2 Image Sensor 1/1.8” 5.0 Megapixel Progressive Scan CMOS with Advanced Starlight Technology Image Size 5 MegaPixel 2592x1944 Resolution 5 MP (2592x1944), 4 MP (2560x1440) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6~10mm (Vari-Focal) Day/Night...
  • Page 47 Detailed Specifications VTD-TND30R5V2 Image Sensor 1/1.8” 5.0 Megapixel Progressive Scan CMOS with Advanced Starlight Technology Image Size 5 MegaPixel 2592x1944 Resolution 5 MP (2592x1944), 4 MP (2560x1440) / 1080P (1920x1080) / 720P (1280x720) / D1/CIF (480x240) Min. Illumination 0 Lux (IR LED ON) Lens 3.6~10mm (Vari-Focal) Day/Night...
  • Page 48 OPTIONAL ACCESSORIES FOR TRANSCENDENT IP CAMERAS VT-TJB01 VT-TJB02 Optional Junction Box for Cable Optional Junction Box for Cable Management for use with all Management for use with Transcendent Bullet and Turret Style Transcendent 30 IR LED Vandal Cameras Domes VT-TJB03 VT-TWM03 Optional Junction Box for Cable Wall Mount for Transcendent 30 IR...
  • Page 49 LIMITED PRODUCT WARRANTY VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser that products manufactured by VITEK are free of any rightful claim of infringement or the like, and when used in the manner intended, will be free of defects in materials and workmanship for a period of three (3) years, or as otherwise stated above, from the date of purchase by the end user.
  • Page 50 CLASS A DIGITAL DEVICE (INDUSTRIAL & COMMERCIAL ENVIRONMENT) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
