- Page 1 ® NETWORK SERVICES DECEMBER 2022 KV4161A ServSwitch CX Quad IP ™ USER GUIDE BLACK BOX CX Quad IP ® ® LOC REM VNC 100 LNK PWR BLACK BOX 724-746-5500 FREE technical support 24 hours per day, 7 days a week.
-
Page 2: Table Of Contents
Main menu .................19 Enterprise installations ............5 General security and configuration steps ........20 ServSwitch CX Quad IP features - front and rear ......6 Registering users and host computers ........20 What’s in the box ................7 What to do if the ADMIN password has been forgotten ..21 What you may additionally need ..........7... - Page 3 Operation Further information ® The front panel indicators ............31 Getting assistance ..............49 Accessing the ServSwitch CX Quad IP ........31 Troubleshooting ................49 Local user access ................32 Appendix 1 – Local setup menus ..........50 Selecting a computer ............32 Functions ................51 Show All Users ...............34 User Preferences ..............52...
- Page 4 Using cascaded computers ..........84 Scaling ...................74 Appendix 8 – Cable and connector specifications ....85 Identities ................75 ServSwitch CX Quad IP to power switch cable ....85 Load / Save ................75 Power switch to power switch daisy chain cable ....85 Appendix 4 - VNC Viewer window options ......76...
-
Page 5: Introduction
SAM formats Many computers The SAMs are available in Each ServSwitch CX Quad IP unit can directly support sixteen computer different formats to support all systems. common types of systems, which Each host system is linked using a Server Access Module (SAM) and... -
Page 6: Creating Larger Installations
The KVM switch is required only to allow a single local user to access all hosts. Global users merely access the alternative IP addresses for the ServSwitch CX Quad IP units. This is one of the jobs handled by WIZARD.NET in order to simplify operation. -
Page 7: Servswitch Cx Quad Ip Features - Front And Rear
ServSwitch CX Quad IP features - front and rear ® The ServSwitch CX Quad IP units pack a great deal of functionality into a compact space. It occupies half of a single 1U rack space and presents most of its connectors at the rear face. -
Page 8: What's In The Box
What’s in the box ® ServSwitch CX Quad IP KV4161A – 16 computer connections, 1 local console connection, 4 global user (network) connections Power adapter and country- B L A ® C K B specific power 4 -7 -5 5 ®... -
Page 9: Installation
Installation ® Mounting The ServSwitch CX Quad IP units offer three main mounting methods: Single unit rack brackets • Supplied four self-adhesive rubber feet • Optional single unit rack brackets These two brackets (plus four screws) extend the size of the ServSwitch CX Quad IP so that it •... -
Page 10: Connections
Connections ® The ServSwitch CX Quad IP provides a great deal of flexibility in its configurations. This chapter details the various connections that can be made to achieve the required installation. Local Global user users page 10 page 11 LOCAL... -
Page 11: Local User
(and mouse) are required during the initial 1 Position a suitable video monitor, keyboard and mouse in the vicinity of the ServSwitch CX Quad IP unit such that their cables will easily reach. configuration. These are also useful during normal use to allow quick local control of any... -
Page 12: Global Users (Ip Network Port)
B O X with an open Internet connection. C X Q Wherever in the network the ServSwitch CX Quad IP is situated, you will need to u a d determine certain configuration issues such as address allocation and/or firewall Networking issues adjustment to allow correct operation. -
Page 13: Computer System (Via Sam)
This action ensures that there are no connection delays or problems as the port is selected. To connect a computer system 1 Ensure that power is disconnected from the ServSwitch CX Quad IP unit and Note: SAMs derive power from the the system to be connected. -
Page 14: Power In Connection
3 Connect the power lead to a nearby main supply socket. 4 . 0 Note: Both the ServSwitch CX Quad IP and its power supply generate heat when in operation and will become warm to the touch. Do not enclose them or place them in locations where air cannot circulate to cool the equipment. -
Page 15: Power Control Port
Power control port To connect and address the switch boxes ® Note: The ServSwitch CX Quad IP unit can be powered on during this procedure, LOCAL GLOBAL The options port of the ServSwitch CX Quad USER USERS however, the switch boxes should be switched off. The configuration steps below IP can be used to connect to one or more are for one particular type of power switch. -
Page 16: Multiple Video Head Connections
4.0A COMPUTER CONNECTIONS COMPUTER CONNECTIONS Note: You must ensure that all ServSwitch CX Quad IP units have their Options serial ports set to ‘Sync Units’ and that their baud rates are identical. These settings can be made local global either via the user configuration menus. -
Page 17: Remote Switching Control
4 . 0 echoed back to the sending device. Note: You must ensure that the ServSwitch CX Quad IP unit has it Options serial ports set to ‘Sync Units’. This setting (together with the baud rate selection) can be made either via the... -
Page 18: Configuration
With security disabled (default setting), a local or remote user attached to the ServSwitch CX Quad IP will have full and unrestricted access to all computers and all ServSwitch CX Quad IP settings. In larger installations, you are strongly recommended to enable security and set up individual user accounts with access privileges. -
Page 19: Initial Configuration
Keybd Layout When the ServSwitch CX Quad IP is switched on for the first time, you Admin Passwd not sufficient. When a password with reasonable strength has been... -
Page 20: Main Menu
1 If the select host menu is not already displayed, press and hold CX Quad IP Login Note: If the security option has been then press using a keyboard attached to a ServSwitch CX Quad IP user enabled, you will be asked for a valid port. Username:... -
Page 21: General Security And Configuration Steps
Registering users and host computers ® All user and host computer registration is achieved solely via the global To enable general security (network) connection to the ServSwitch CX Quad IP unit. See Appendix 2 - Main menu. 1 Display the Configuration pages via viewer for details. -
Page 22: What To Do If The Admin Password Has Been Forgotten
If the ADMIN password is forgotten, you will not be able to access the ServSwitch CX Quad IP to add or edit users and computer names, unless you have given other users admin privileges. This situation may be resolved by performing a complete reset to return the ServSwitch CX Quad IP. -
Page 23: Clearing Ip Access Control
Clearing IP access control ® This option removes all entries from the IP access control feature within the ServSwitch CX Quad IP. What is IP access control? The IP access control feature (configurable by a remote admin user) allows certain network address ranges to be denied access to the ServSwitch CX Quad IP. -
Page 24: Full Configuration By Global User
Full configuration by global user ® Once the basic features have been configured using the ServSwitch CX Quad IP To configure the unit from a global user location configuration menus, further changes can be made by authorized global users 1 Use either the VNC Viewer or a standard web browser to make remote Global user access via the VNC interface. -
Page 25: Encryption Settings
• Prefer off - This setting will configure an un-encrypted link if the ServSwitch CX Quad IP will allow it, otherwise it will be encrypted. • Prefer on - If the ServSwitch CX Quad IP allows it, this setting will configure an encrypted link, otherwise it will be un-encrypted. -
Page 26: Networking Issues
Networking issues ® Thanks to its robust security the ServSwitch CX Quad IP offers you great flexibility in how it integrates into an existing network structure. The ServSwitch CX Quad IP is designed to reside either on an internal network, behind a firewall/router or alternatively with its own direct Internet connection. - Page 27 ‘192.168.47.10’ then VNC Viewer users will need to enter: to minimize the number of open ports. The ServSwitch CX Quad IP usually uses two separate port numbers, however, these are easily changeable and can even 192.168.47.10::11590...
- Page 28 To discover a DHCP-allocated IP address ® Once a DHCP server has allocated an IP address, you will need to know it in order to access the ServSwitch CX Quad IP via a network connection. To discover the allocated IP address: local configuration menus...
- Page 29 Placing ServSwitch CX Quad IP alongside the firewall ® The ServSwitch CX Quad IP is built from the ground-up to be secure. It employs Security can be further improved by using the following suggestions: a sophisticated 128bit public/private key system that has been rigorously •...
-
Page 30: Power Switching Configuration
Power switching configuration ® Power control sequences Power switch configuration comprises two main steps: Note: The settings given below are for one particular model of power switch - other power switches may require different settings. Please refer to your power •... -
Page 31: Upgrading Servswitch Cx Quad Ip Models
6 Click the ‘Upgrade Firmware’ button. This dialog will be displayed: 9 Select which portion of the ServSwitch CX Quad IP that you wish to upgrade: • Tick the ’Main’ option to upgrade the ServSwitch CX Quad IP unit itself. -
Page 32: The Front Panel Indicators
Operation ® Accessing the ServSwitch CX Quad IP The front panel indicators The ServSwitch CX Quad IP provides two ways to gain access: • Local user access, or • Global user access via IP network link. LOC REM VNC 100... -
Page 33: Local User Access
• If the port address is a single character, release all of the keys. and they signal to the ServSwitch CX Quad IP that you wish to control it, rather • If the port address is two or more characters, release the first numeral than the host computer. - Page 34 Standard hotkeys To select a computer using the Select Host menu ® The range of hotkey combinations are as follows: 1 Display the Select Host menu in one of two ways: Note: If your hotkeys have been changed, substitute them for •...
-
Page 35: Show All Users
® To select a computer using mouse buttons The ServSwitch CX Quad IP features a straightforward security system that helps Note: This procedure works only with three-button or IntelliMouse devices and to prevent unauthorized access to some, or all connected computers. -
Page 36: The Confirmation (Status) Box
The confirmation (status) box User preferences and functions ® The ServSwitch CX Quad IP provides In addition to enabling or disabling the confirmation box, you can also: CX Quad IP Status the option of a confirmation box that is • Select the screen saver style,... -
Page 37: Orange Dot Indicators In The Select Host Menu
Orange dot indicators in the Select Host menu ® Within the Select Host menu, each listed host has a coloured dot associated with it to indicate its general status: Green for accessible and Red for inaccessible. CX Quad IP Select Host Computer Port Computer 01... -
Page 38: Global User Access
Global user access ® Global users access the ServSwitch CX Quad IP using a viewer and a network/ internet link. There are two types of viewer: a standalone VNC Viewer or a VNC ® Java application used within a standard web browser. -
Page 39: Global User Access Via Vnc ® Viewer
The VNC Viewer is a compact application that runs on your IP-connected ‘global’ system and allows you to view and use the ServSwitch CX Quad IP and its host computer(s). VNC Viewer is readily available from a number of different sources: Downloading VNC Viewer from the ServSwitch CX Quad IP •... -
Page 40: Global User Access Via Web Browser
(supported versions) to gain access to the ServSwitch CX Quad IP and its host computer(s). As soon as you make contact with the ServSwitch CX Quad IP it will begin downloading a small Java application to your browser, which will be used only for the duration of your connection. -
Page 41: Using The Viewer Window
Options button of the VNC Viewer synchronized. encountered. Click this computer. when entering the ServSwitch CX Quad IP address during log on. button when you first visit a new screen. Adjust the Threshold setting Ensure that the video Threshold setting is set higher than the automatic setting suggests. -
Page 42: Mouse Pointers
Remote host cursor Configure This option is displayed only when you are logged on as the ‘admin’ user. When selected it provides access to a wide range of ServSwitch CX Quad IP settings. Additionally, for fast network connections, the VNC Viewer also Appendix 2 - Configuration pages via viewer for more details. -
Page 43: Auto Calibrate
Auto calibrate Re-synchronize mouse ® When you visit a host computer for the very first time, your viewer needs to If you find that your local mouse pointer and that of the host are not correctly determine the optimum video and mouse settings for that particular computer. synchronized, use this feature to re-align their movements. -
Page 44: Controls
Controls ® When clicked, this button reveals a menu of options concerned with keyboard, video and mouse operation. Single Mouse Mode Mouse Control This mode is for fast network connections where This option displays a mouse control dialog and is useful when the remote the cursor response is sufficient to provide instant cursor is failing to respond correctly to your mouse movements, even after using the Resync mouse option. - Page 45 (to the host) that are needed regularly or that are trapped by the special keys that are present on Sun keyboard. Use this when using a standard ServSwitch CX Quad IP. keyboard while connecting to a Sun system. Notes: The Enable/Disable status of the Sun translation mode is retained, so this mode selection only needs to be done once per host.
- Page 46 The phase setting adjusts the alignment of the host video Note: When the ServSwitch CX Quad IP is used with one or more other output and the remote system switches, the threshold needs to be higher than 32 due to the signal ‘noise’...
- Page 47 Select this option to display a list of all users who are currently logged into the This option contains video signal settings that do not normally need to be ServSwitch CX Quad IP unit together with the host computer (and port) that adjusted.
-
Page 48: Vnc ® Hotkey Selection
Note: If your hotkeys have been changed, substitute them for ‘hotkeys’ and they signal to the ServSwitch CX Quad IP that you wish to the examples given here. control it, rather than the computer. However, if these particular hotkeys... -
Page 49: If You Need To Enter A Port Number
CX Quad IP will allow it, otherwise it will be encrypted. number (in this example, the required port number is 8000), • Prefer on - If the ServSwitch CX Quad IP allows it, this setting will configure i.e. http://192.168.0.3:8000 an encrypted link, otherwise it will be un-encrypted. -
Page 50: Further Information
IP access control section. • Appendix 1 - Configuration menus • If the ServSwitch CX Quad IP is situated behind a firewall, check that the • Appendix 2 - Configuration pages via viewer relevant ports are being allowed through the firewall and are being •... -
Page 51: Appendix 1 - Local Setup Menus
Appendix 1 – Local setup menus ® The ServSwitch CX Quad IP local setup menus allow a range of settings to be made both to the installation as a whole and to parts of the system accessed by each user. -
Page 52: Functions
Power Control Restore Standard Mouse The options within this section are usable only when the ServSwitch CX Quad IP This option is used to resume standard mouse operation if it has ceased to is used in conjunction with one or more external power switch units and when... -
Page 53: User Preferences
User Preferences ® The User Preferences are system operating parameters that are independently selectable CX Quad IP User Prefs for each user and affect only their screen. Screen Saver Moving Logo To get here Confirmation Box Enabled 1 From a local keyboard, log on as a Save Cancel standard or ‘admin’... -
Page 54: Global Preferences
The ServSwitch CX Quad IP can be set to blank the screen after no keyboard or mouse activity has been detected for a selected timeout period. If preferred, the user can blank the screen manually by selecting channel ‘0’... -
Page 55: Setup Options
CX Quad IP. Each user is allocated access rights to computers by the system with full access to all the computers. The ServSwitch CX Quad IP can be set to administrator and they are only able to see the computers that they have access automatically logout unattended user consoles when the screen saver kicks in. -
Page 56: Configuration
4 Select ‘Configuration’ and press • Unit Configuration IP admin password, encryption settings, etc. • Network Configuration IP address, net mask, VNC port, etc. • Serial Configuration Options port usage and Baud rate. • Reset Configuration Completely resets the ServSwitch CX Quad IP unit. -
Page 57: Unit Configuration
Enter the password that will be used to gain administrator access to the 10% but is highly secure against third party intrusion. ServSwitch CX Quad IP. There can only be one admin user and only that user is given access to the configuration menus. The admin password background will be red until a reasonably secure password has been entered, although this is only advisory as any password or no password may be entered. -
Page 58: Network Configuration
This is the logical link through which communications with a remote web it will supply three things to the ServSwitch CX Quad IP: an IP address, an IP browser will be channelled. The default setting of 80 is an established standard network mask (also known as a Subnet mask) and a Gateway address. -
Page 59: Serial Configuration
Determines whether the RS232 serial OPTIONS port at the rear of the unit will be used for connection to power control switches or to synchronize the operation of two ServSwitch CX Quad IP units. Options Baud Settings: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 This option determines the speed of the RS232 serial OPTIONS port. -
Page 60: Reset Configuration
Reset Configuration ® This option allows you to completely reset the IP portion of the ServSwitch CX Quad IP CX Quad IP Reset Config unit. WARNING: Continuing will cause WARNING: This process will remove all your existing configuration to network settings and return the unit to use be erased. -
Page 61: Appendix 2 - Configuration Pages Via Viewer
To access the remote configuration pages global connection 1 Make a to the ServSwitch CX Quad IP unit and login as the admin user. 2 Once logged in, click the Configure button in the top right corner of the window. -
Page 62: User Accounts
1 and 16 characters in length. It is important to note, however, that the password background remains shaded in amber while the ServSwitch CX Quad IP considers your entered password to be too easy to guess. A suitable password is best constructed using a mixture of more than 6 letters, numbers and punctuation characters. -
Page 63: Unit Configuration
2. Enter the password that will be used to gain administrator access to the ServSwitch CX Quad IP. There can only be one admin user and only that user is Advanced Unit Configuration given access to the configuration menus. -
Page 64: Advanced Unit Configuration
This option is used during calibration to account for latency delays that may be caused as signals pass through a device. During calibration, the ServSwitch CX Quad IP waits for 40ms after each mouse movement before sampling the next. If a device adds a significant delay to the flow of data, the calibration process can be lengthened or may fail entirely. -
Page 65: Time & Date Configuration
ServSwitch CX Quad IP unit. Optionally enter a recognized timezone specifier related to the current position of the ServSwitch CX Quad IP unit. When an NTP server is used, the specifier will be used to provide the correct real time. -
Page 66: Network Configuration
DHCP server on the network. If such a server is located, it will supply three things to the ServSwitch CX Quad IP: an IP address, an IP IP Access Control network mask (also known as a Subnet mask) and a Gateway address. -
Page 67: Setting Ip Access Control
Setting IP access control ® To define a new IP access control entry The golden rule with this feature is ‘Include before you exclude’ or to put it 1 Click the Add button to display a popup dialog: another way ‘Arrange allowed addresses in the list before the denied addresses’. This is because the positions of entries in the list are vitally important. -
Page 68: Serial Port Configuration
This option determines whether the RS232 serial OPTIONS port at the rear of the unit will be used for connection to power control switches or to synchronize the operation of two ServSwitch CX Quad IP units. Baud Rate This option determines the speed of the RS232 serial OPTIONS port. The other... -
Page 69: Host Configuration
This page provides the opportunity to configure various details for each of the To create a new host entry host systems that may be connected to the ServSwitch CX Quad IP. Each entry 1 Click one of the host entries to reveal a Host configuration dialog. -
Page 70: Logging And Status
Logging and status ® This screen provides various details about the user activity on the ServSwitch CX To copy and paste the log Quad IP unit. You can copy the information listed within the log and paste it into another application. -
Page 71: Ldap Configuration
LDAP configuration ® The ServSwitch CX Quad IP can optionally use the industry standard LDAP (Lightweight Directory Access Protocol) to allow user authentication to occur in conjunction with an externally held database. This screen allows you to configure details related to the creation of an LDAP link to an external directory service, such as an Active Directory server. -
Page 72: Appendix 3 - Vnc ® Viewer Connection Options
• Hextile – This method offers better performance than the ZRLE when used over a high speed network because there is no need for the ServSwitch CX Quad IP to spend time highly compressing the data. • Raw – This is a primitive, uncompressed method that is mainly used for technical support issues. -
Page 73: Inputs
When ticked, this feature reduces the mouse movement information that is When selected, allows keyboard, sent to the ServSwitch CX Quad IP and host system. This is useful for slow mouse and clipboard data to be connections and you will notice that the remote cursor will catch up with the transferred between server and local cursor roughly once every second. -
Page 74: Misc
Render cursor locally This option does not currently apply to ServSwitch CX Quad IP connections. Allow dynamic desktop resizing IMPORTANT: If you make any changes to the options given here and wish to When ticked, the viewer window will be automatically resized whenever the retain them for successive connection sessions, you must save the changes. -
Page 75: Scaling
Scaling ® No Scaling No attempt is made to make the screen image fit the viewer window. You may need to scroll horizontally and/or vertically to view all parts of the screen image. Scale to Window Size Adjusts the server screen image to suit the size of the viewer window. -
Page 76: Identities
Defaults - Save If an existing ServSwitch CX Quad IP is fully reconfigured then it will need When clicked, saves the current connection options as the default set that will to issued with a new identity. In this case the previous identity, listed in this be used in all subsequent VNC connections. -
Page 77: Appendix 4 - Vnc ® Viewer Window Options
New connection... Displays the connection dialog so that you can log on to a different ServSwitch CX Quad IP or VNC server location. Options... Displays the full range of connection options - see Appendix 3 for more details. -
Page 78: Appendix 5 - Browser Viewer Options
Selects the highest level of encoding for communications between the browser over a high speed network because there is no need for the ServSwitch CX and the ServSwitch CX Quad IP. Quad IP to spend time highly compressing the data. -
Page 79: Appendix 6 - Addresses, Masks And Ports
192.168.142.22. The sending device would perform several calculations: The important parts of the whole number depend on where you are. If you were based in the same local area as Black Box, there would be no point in dialing out Sending Destination of the US, or even out of the area. -
Page 80: Net Masks - The Binary Explanation
Net masks - the binary explanation ® To really understand the operation of a net mask it is necessary to delve deeper into the life blood of computers – binary; this is native digital, where everything is either a 1 (one) or 0 (zero), on or off, yes or no. previous page The net mask operation described on the is known as a ‘bit-wise... -
Page 81: Calculating The Mask For Ip Access Control
Calculating the mask for IP access control ® The IP access control function uses a standard IP address and a net mask The permissible mask values (for all octets) are as follows: notation to specify both single locations and ranges of addresses. In order to Mask octet Binary Number of addresses encompassed... -
Page 82: Ports
® Viewer or web browser to make contact with your ServSwitch CX Quad IP, it is necessary generally wouldn’t expect the accounts department to share the same telephone with the technical department. Although their calls may all be related to the for the firewall to allow communication through a particular numbered port to same company, they concern very different aspects of that company. -
Page 83: Appendix 7 - Cascading Multiple Units
The cascade tree computers using ServSwitch CX Quad IP units, The diagram shows how an ServSwitch CX Quad IP unit and multiple there are two main ways to achieve this: ServSwitch CX Uno units can be cascaded to two levels. Computer systems can be connected at any level. -
Page 84: Connecting Units In Cascade
Connecting units in cascade ® The method for cascading ServSwitch CX Quad IP and ServSwitch CX Uno units To connect units in cascade is straightforward and requires no hardware settings or lengthy configuration 1 Ensure that power is disconnected from the process. -
Page 85: Addressing Computers In A Cascade
The first time that you make a connection between an ServSwitch CX Quad IP and an ServSwitch CX Uno, the master unit will detect this and ask (via the on The unique screen menu) if you want to automatically add computers. -
Page 86: Appendix 8 - Cable And Connector Specifications
Appendix 8 – Cable and connector specifications ® ServSwitch CX Quad IP to power switch cable Multi-head synchronisation cable 9pin D-type female 4pin RJ9 MASTER end SLAVE end 9pin D-type female 9pin D-type female Use this cable when two ServSwitch CX Quad IP devices are being synchronized. -
Page 87: Appendix 9 - Hotkey Sequence Codes
Appendix 9 – Hotkey sequence codes ® These codes are used when defining hotkey switching sequences (macros) for host computers and allow you to include almost any of the special keys on the keyboard. Permissible key presses Creating macro sequences Hot key macro sequences can be up to 256 characters long. -
Page 88: Appendix 10 - Supported Video Modes
Appendix 10 – Supported video modes ® The following video modes are supported and can be automatically configured by the ServSwitch CX Quad IP units. Support for VESA GTF (Generalized Timing Formula) is available and can be enabled via the Advanced Unit Configuration screen. -
Page 89: Safety Information
• If you use a power extension cord with the ServSwitch CX Quad IP, make sure the total ampere rating of the devices plugged into the extension cord does not exceed the cord’s ampere rating. -
Page 90: End User Licence Agreement
® SOFTWARE, THE SERVICE OR THE INFORMATION, RELIANCE ON THE DATA THE SERVSWITCH CX Quad IP PRODUCT (“the PRODUCT”). THE SOFTWARE PRODUCED OR INABILITY TO USE THE SOFTWARE, THE SERVICE OR THE IS PROVIDED TO ENABLE YOU TO OPERATE THE PRODUCT. BY USING ALL... -
Page 91: Radio Frequency Energy
Radio Frequency Energy ® A Category 5 (or better) twisted pair cable must be used to connect the units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. All other interface cables used with this equipment must be shielded in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. -
Page 92: Normas Oficiales Mexicanas (Nom) Electrical Safety Statement
Normas Oficiales Mexicanas (NOM) electrical ® safety statement Instrucciones de seguridad 15 En caso de existir, una antena externa deberá ser localizada lejos de las 1 Todas las instrucciones de seguridad y operación deberán ser leídas antes de lineas de energia. que el aparato eléctrico sea operado. - Page 93 ® © 2022 Black Box Corporation All trademarks are acknowledged. Documentation by: www.ctxd.com...
- Page 94 Index ® Hotkeys Access Baud rate Configuration 17 Encryption key 18 local setting 58 initial IP 23 Encryption settings 24 changing 20 local and remote users 32 Access control remote setting 67 menus 19,50 viewer 48 codes and macros 86 selecting computers 32,47 configuration 66 Binary...
- Page 95 ® Local connection 32 Octets Rack mounting 8 Selecting Unit Configuration 56,62 Local network IP address 78 Raw 71,77 cascaded computers 35 Unit name connection 25 Operation 31 Recover computers 32 local setting 56 Local user Options port upgrade failure 30 with hotkeys 32,47 remote setting 62 connection 10...
