In addition to scaling the resolution, the camera is also capable of scaling down the frame rate to save
bandwidth. Each channel can select from full frame rate, half frame rate, quarter or sixth frame rate.
For example, it is possible to configure a primary stream of 1920x1080 at 60 fps simultaneously with a
secondary stream at 480p at 10 fps.
The maximum performance for two channels is two 1080p60 streams.
3.0

PACKAGE CONTENTS

HE2K PCB Assembly
*NOTE: additional cables may be required to connect your secondary camera. Contact Sales for more
information about available cables and compatible cameras.
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
KEL Ribbon Cable
12V 1 Amp AC Adapter-
Optional

Figure 2 HE2K-DCK-1X Package Contents

9
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
HE2K-DCK-1X User Instructions
DOC-USR-0122-05
Serial Cable-
Optional
Gender Changer-
Optional
