GENERAL DESCRIPTION

The HE2K-DCK-1X is a H.265/HEVC, H.264 and MJPEG video encoder designed to be a companion to the Sony
FCB-EV7520 block camera. It is capable of accepting HD video from the camera at 60 frames per second and
producing IP streams that can be sent on a standard Ethernet cable. The HE2K-DCK-1X has one KEL
connector for Sony FCB-EV7520 or compatible cameras.
58 mm

Figure 1: HE2K -DCK-1X Board Stack Dimensions
