Emergency Locator Transmitter
Description, Operation, Installation and Maintenance Manual
This manual includes data for the equipment that follows:
Component
Emergency Locator Transmitter
ME406 Series
Part No.
Model No.
453-6611
ME406P
25-62-31
Initial Issue JAN 05/2007
ARTEX PRODUCTS / ACR ELECTRONICS, INC.
5757 Ravenswood Rd, Ft. Lauderdale, FL 33312
Page 1 of 74
MAY 28/2020
570-1700 Rev. V
Cage Code: 18560
