Page 1
Supplement Artex ELT 1000 406 MHz ELT System When Artex ELT 1000 406 MHz ELT System is installed on the aircraft, this POH Supplement is applicable and must be inserted in the Supplements section (Section 9) of the Pilot’s Operating Handbook.
Page 2
1. LED Annunciator 2. Remote Switch 3. Antenna 4 Remote Cable 5. Main Control Switch 6. Antenna Jack 7. Attach Straps 8. Artex ELT 1000 SR22_FM09_3681 Figure - 1 Artex ELT 1000 System 2 of 6 P/N 13772-156 Original Issue: 11-20-14...
Page 3
Installation of the subject propeller adds the following optional (Sym = O) equipment at the weight and arm shown in the following table. Unit ATA / Description Part Number Weight Item Inches 25-01 Artex ELT 1000 and Batteries 33940-001 229.5 P/N 13772-156 3 of 6 Original Issue: 11-20-14...
Page 4
Supplements SR22 / SR22T Section 7 - Systems Description The airplane is equipped with a self-contained Artex ELT 1000 406 MHz emergency locator transmitter (ELT) system. The transmitter unit is automatically activated upon sensing a change of velocity along its longitudinal axis exceeding 4 to 5 feet per second, or upon sensing deployment of the Cirrus Airframe Parachute System (CAPS).
Page 5
Cirrus Design Section 9 SR22 / SR22T Supplements “ARM/OFF” - “TEST”, and a red LED annunciator. The red LED annunciator flashes when the ELT is transmitting. Section 8 - Handling, Servicing & Maintenance The ELT batteries must be inspected in accordance with the Airplane Maintenance Manual, 5-20 - Scheduled Maintenance Checks.
Page 6
Section 9 Cirrus Design Supplements SR22 / SR22T is disconnected. Therefore, it does not check the integrity of the ELT system or provide the same level of confidence as does an AM radio. 1. Tune aircraft receiver to 121.5 MHz. 2.
