Emergency Locator Transmitter
Description, Operation, Installation and Maintenance Manual
This manual includes data for the equipment that follows:
Component
Emergency Locator Transmitter
Emergency Locator Transmitter
C406-2 Series
Part No.
453-5000
453-5001
25-62-11
Model No.
C406-2
C406-2HM
ARTEX PRODUCTS / ACR ELECTRONICS, INC.
5757 Ravenswood Rd, Ft. Lauderdale, FL 33312
Page 1 of 66
MAY 28/2020
570-5000 Rev. U
Initial Issue JUN 30/1999
Cage Code: 18560
