Rocstor Y10A201-B1 User Manual

USB Type-C to dual DisplayPort Adapter
with DP1.4 Alt mode
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This is a Rocstor Premium Type-C to dual DisplayPort Adapter, allowing to extend
Type-C port of the host to 2 DisplayPort displays with ultra high de nition max
4K/60Hz for each display simultaneously. Supporting MST function, dual displays can
be showed with di erent video contents simultaneously. It can work on all DP Alt
mode supported Type-C/Thunderbolt PC.
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
User Manual
Y10A201-B1
®
Features
Upstream:
USB Type-C Male
(Connect to host computer)
Downstream:
DisplayPort x2 Female
Features
• Support Type-C input, 2 DisplayPort outputs
• Support DP1.4 Alt mode with max 8.1Gbps per lane, 32.4Gbps 4 lanes
• Support DP1.4 with max 4K/60Hz for one video output
• Support to output dual 4K/60Hz with di erent pictures under MST mode
when working on Windows System.
Note: to achieve dual max 4K/60Hz, the host should support DP1.4 Alt mode,
when working on DP1.2 host, dual max 4K/30Hz due to bandwidth limitation.
• Support to output dual 4K/60Hz with the same picture under SST mode
when working on Mac OS System
• Support 8/10/12 bit color depth output
• Support output pixel format RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0
• Support HDCP2.2&1.4
• Support HDR
Notes: HDR support ensures every moment of a video is displayed at its ideal
values for depth, detail, brightness, contrast and wider color gamuts—on a
scene-by-scene or even a frame-by-frame basis
Speci cation
Input / Output Connector
Input
Output
HDMI
Resolution
HDR
HDCP Version
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Power Requirement
Power Source
Standby Power Consumption
Accessory
s
User Manual
Warranty
Limited Warranty
Type-C Male x1
DisplayPort Female x2
Max one 4K/60Hz or dual 4K/60Hz
Support
HDCP2.2&1.4
0°C to + 45°C - (32°F to + 113°F)
10% to 85 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
5% to 90 % RH (no condensation)
FCC, CE
Bus Power
≤0.5W
English Version
2 Year
mode
