THORLABS PDA10A2 User Manual page 10

Si Amplified Fixed Gain Detector
On/Off Switch
Output
Package Size
PD Surface Depth
Weight, Detector Only
Accessories
Operating Temp
Storage Temp
AC Power Supply
5
Input Power
4
Measured from the active area to the start of the threads on the housing body. The detector
active area surface is flush with the front of the housing body.
Although the power supply is rated for 6 W, the detector's actual usage is <5 W over the full
5
operating range.
Page 8
General
4
Slide
BNC (DC Coupled)
2.79" x 1.96" x 0.89"
(70.9 mm x 49.8 mm x 22.5 mm)
0.09" (2.2 mm)
0.10 kg
SM1T1 Coupler
SM1RR Retainer Ring
10 to 50 °C
-25 to 70 °C
AC - DC Converter
6 W
100 V / 120 V / 230 V, 50 - 60 Hz
TTN134700-D02
