iPF680
•
You can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
•
Divisions
You can change the number of divisions of grid lines so that they serve as a guide to laying out objects.
•
You can input between 1 and 10.
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
•
Grid Color
Select the grid line color.
•
Print Object Frames
You can print the object border.
•
If you do not want to print the object border, deselect the Print Object Frames check box.
Note
•
Object Frame Style
You can select the object frame style for printing.
The following settings are available for the object frame style.
Setting
Solid Line
Dotted Line
Dashed Line
•
Auto Arrange Spacing
Change the object-to-object spacing to be applied in the operation of laying out objects automatically.
•
You can input between 0.0 and 100.0(mm) (between 0.00 and 3.94(inch)).
•
You can change the numbers by clicking either ▲ button or ▼ button.
Note
Page Setup Dialog Box
Page Setup Dialog Box
This dialog box appears when you select Page Setup from the File menu.This dialog box provides selections for set-
ting the media size, orientation and other important features.
•
Paper Orientation
This selects the paper orientation.
User's Guide
You can print the solid line as the frame style.
You can print the dotted line as the frame style.
You can print the dashed line as the frame style.
Page Setup Dialog Box
Details
333
