Know Your Cordless Chain Saw
Read the owner's manual and safety rules carefully before operating your cordless chain saw. Compare the illustration
below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this
manual for future reference.
1. Cutting bar sheath
2. Spiked bumper
3. Front hand guard
4. Front hand grip
5. Battery charge level indicator
6. Push button for battery indicator
7. 40 V 4.0 Ah EcoSharp
or 40 V 5.0 Ah EcoSharp
(model IBAT40XR) lithium-ion
battery – Sold separately
8. Push lock button
9. Rear hand grip
10. Chain/sprocket end cover
11. Ring nut
12. Chain tension adjustment knob
13. 16" (405 mm) Oregon guide bar
14. 16" (405 mm) Oregon chain
15. Oil tank cap
16. Oil level indicator window
17. Safety lock button
18. Trigger switch
19. 40 V EcoSharp
battery charger
®
(model iCHRG40) or 40 V
EcoSharp
SWIFT battery charger
®
(model iCHRG40QC) – Sold separately

Technical Data

No Load Speed
Battery Voltage*
Battery Capacity
Charging Time
*Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage under typical load is 36 volts.
7
8
(model iBAT40)
®
PRO
®
9
15
16
4400 ± 10% rpm
40 V D.C.
4.0 Ah (model iBAT40)
5.0 Ah (model iBAT40XR)
2.5 – 3 hours
(using iBAT40 with iCHRG40)
3 – 3.5 hours
(using iBAT40XR with iCHRG40)
4
5
6
10
17
18
Battery Runtime (Max)
Motor
Bar Chain Length
Cutting Thickness (Max)
Oil Tank Capacity
Weight (chain saw alone)
7
3
1
2
14
13
12
11
40 min (using iBAT40)
65 min (using iBAT40XR)
600 W brushless
16 in. (405 mm)
14.6 in. (371 mm)
2.4 fl oz (70 ml)
9.5 lbs (4.3 kg)
19
