Technical Data - SNOWJOE SUNJOE SWJ800E Operator's Manual

Know Your Electric Pole Chain Saw
Read the owner's manual and safety instructions carefully before operating the pole chain saw. Compare the illustration below
to the pole chain saw in order to familiarize yourself with the location of the various controls and adjustments. Save this manual
for future reference.
1. 8 in. guide bar
2. 8 in. cutting chain
3. Sprocket cover
4. Oil tank cap
5. Sprocket cover bolt
6. Cutting bar sheath
7. Collar
8. Trigger switch
9. Extension cord restraint hook
10. Safety lock button
10

Technical Data

Rated Voltage
Power
Bar/Chain Length
Telescopic Shaft
Overhead Reach
8
9
120 V ~ 60 Hz
6.5 A
8 in. (20.3 cm)
5.6 ft to 8.7 ft
(1.7 m to 2.65 m)
15 ft (4.6 m)
7
Cutting Thickness
Oil Tank Capacity
No Load Speed
Weight
5
4
3
2
6
5
Max: 7.5 in. (19 cm)
Recommended: 6.5 in. (16.5 cm)
2.0 fl oz (60 ml)
6,000 rpm
7 lbs (3.2 kg)
1
