Go Power Weekender SW Owner's Manual page 14

Diagram 3
Parallel Wiring Between a Standard Junction Box and an MC4 Cable Junction Box
MC4 Extension Cable
(MC4 Output 10)
Parallel Wiring Between a Standard Junction Box and an Existing MC4 Cable Junction Box
Existing Power
Cable to Solar
Controller
14
Negative MC4 Parallel Connector - Female
Positive MC4 Parallel Connector - Male
MC4 Extension Cable (MC4 Output 10)
www.
Existing MC Power Cable
to Solar Controller
Note: solar module junction box and MC4 cables many not
be exactly as shown.
MC4 Parallel - Male
gp
electric.com
Weekender SW GP-RV-80
GP-RV-80E
Weekender HD GP-RV-95
GP-RV-95E
Solar Elite GP-RV-155E GP-RV-155
Solar Extreme
MC4 Parallel - Female
