Condensing wall mounted boiler
MURELLE HE 50 R I - 50 R E
 INSTALLATION AND SERVICE INSTRUCTIONS
EN
Gas Safety Certificate AS/NZS 5263.1.2 LN: SAI-400271
CAUTION
This product must be installed exclusively by professionally qualified personnel in accordan-
ce with the requirements of the standards AS/NZS 5601, AS/NZS 3500, AS/NZS 3000 (current
version) of the local gas, electricity authorities and other relevant legislation.
Fonderie SIME S.p.A
Cod. 6322971A - 04/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MURELLE HE 50 R E and is the answer not in the manual?

Questions and answers

Related Manuals for Sime MURELLE HE 50 R E

Summary of Contents for Sime MURELLE HE 50 R E

  • Page 1 Condensing wall mounted boiler MURELLE HE 50 R I - 50 R E  INSTALLATION AND SERVICE INSTRUCTIONS Gas Safety Certificate AS/NZS 5263.1.2 LN: SAI-400271 CAUTION This product must be installed exclusively by professionally qualified personnel in accordan- ce with the requirements of the standards AS/NZS 5601, AS/NZS 3500, AS/NZS 3000 (current version) of the local gas, electricity authorities and other relevant legislation. Fonderie SIME S.p.A Cod. 6322971A - 04/2018...
  • Page 2 SAFE HANDLING This boiler may require 2 or more operatives to move it into its installation site, remove it from its packaging and during movement into its installation location. Manoeuvring the boiler may include the use of a sack truck and involve lifting pushing and pulling. Caution should be exercised during these operations. Operatives should be knowledgeable in handling techniques when performing these tasks and the following pre- cautions should be considered: – Grip the boiler at the base – Be physically capable – Use personal protective equipment as appropriate e.g. gloves, safety footwear. During all manoeuvres and handling actions, every attempt should be made to ensure the following unless unavoi- dable and/or the weight is light. – Keep back straight – Avoid twisting at the waist – Always grip with the palm of the hand – Keep load as close to the body as possible – Always use assistance WARNING Caution should be exercised when performing any work on this appliance.
  • Page 3 USER INSTRUCTIONS CONTENTS LIGHTING AND OPERATION..........................3 HANDOVER INSTRUCTIONS ..........................5 SERVICE RECORDS...............................6 WARNINGS – In case of fault and/or incorrect equipment operation, deactivate it, without making any repairs or taking any direct action. Apply only to qualified technical personnel. – Boiler installation and any other assistance and/or maintenance activity must be carried out by qualified registered as a licenced gas technician. Under no circumstances, the devices sealed by the manufacturer can be tampered with. – It is absolutely prohibited to block the intake grilles and the aeration opening of the room where the equipment is installed. – The manufacturer shall not be held liable for any damage caused by improper use of the appliance. Apre – This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. Apre LIGHTING AND OPERATION BOILER IGNITION (fig. 1) The first ignition of the boiler must be carri- ed out by qualified technical personnel. Successively, if it is necessary to start up the Circuito riscaldamento 2 boiler again, adhere strictly to the following instructions: open the gas tap to allow the flow of the fuel and move the main switch of...
  • Page 4 If the error persists, request assistance – ALL 70 and ALL 71 splay shows an alarm and the blue lumi- from qualified technical personnel. These alarms appear on the SIME HOME nous bar becomes red. Descriptions of the Apre remote control display. Request assi- errors with the relative alarms and solu-...
  • Page 5 HANDOVER INSTRUCTIONS Handover Instructions No. Description ✔ when done Fill in all the details on this Boiler manual Instruct the owner/users on the correct operation of this heating system, this includes how to turn the system on and off, adjust the time and temperature settings. How to turn the heating system off in summer and on for winter. Where all the major items are, their functions and how to check and turn them on or off. Simple fault resolution i.e. power on. How to check and remove air in the radiators. Give them a bleed key. The importance of this SERVICE RECORDS, keeping safe & accessible when required Recommend that the boiler should be serviced at/before the start of winter next year then every two years.
  • Page 6 SERVICE RECORDS Service – 1 – year 1 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note Service – 2 – year 3 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note Service – 3 – year 5 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note Service – 4 – year 7 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note...
  • Page 7 Service – 5 – year 9 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note Service – 6 – year 11 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note Service – 7 – year 13 Date Service technician Name PIC Licence No. Service Company Contact phone number Work Completed Note...

  • Page 8: Table Of Contents

    DESCRIPTION OF THE APPLIANCE CONTENTS CHARACTERISTICS ............................9 DIMENSIONS TECHNICAL FEATURES ............................ 11 FUNCTIONAL DIAGRAM ............................ 12 MAIN COMPONENTS ............................13 APPROXIMATE MINIMUM DISTANCES BOILER ELECTRICAL ............................14 DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION. DO NOT USE OR STORE FLAMMABLE MATERIALS IN OR NEAR THIS APPLIANCE. DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIACE. DO NOT MODIFY THIS APPLIANCE. THE APPLIANCE IS NOT SUITABLE FOR POOL OR SPA HEATING.

  • Page 9: Characteristics

    CHARACTERISTICS 100% of power) designed for single in- For optimum installation and operation, stallation and in modular systems with always follow the instructions provided in MURELLE HE 50 R I/E are premixed gas several generators connected in sequen- this manual. condensation for heating only with wide ce/cascade and independent from each range of power modulation (from 20% to other.
  • Page 10 MURELLE HE 50 R E FIXTURES R Heating return G 1” (UNI - ISO 228/1) M Heating flow G 1” (UNI - ISO 228/1) G Gas connection G 3/4” (UNI - ISO 228/1) R3 D.H.W. tank return G 1” (UNI - ISO 228/1) S3 Condensation outlet ø 25 S1 Safety valve discharge C System loading G 1/2” (UNI - ISO 228/1) Fig. 1/a...

  • Page 11: Technical Features

    TECHNICAL FEATURES MURELLE HE 50 R I / E Heat output Nominal (80-60°C) 46.8 Nominal (50-30°C) 51.2 Reduced (80-60°C) Reduced (50-30°C) 10.5 Heat input nominal * kW - MJ/h 53.3 - 192.0 Heat input reduced kW - MJ/h 10.6 - 38.2 Max useful yield (80-60°C) 87.7 Max useful yield (50-30°C) 96.0 Losses after shutdown to 50°C Max/Min inlet water pressure kPa 400 / 50...

  • Page 12: Functional Diagram

    FUNCTIONAL DIAGRAM 17 Safety valve 3.5 bar (343 kPa) 1 Gas valve 18 Colector signal 2 Condensate drain tap 19 Pressure probe 4 Fan 20 Connecting pipe 5 flow sensor (SM) Heating 6 Safety thermostat 95°C 7 Exhaust sensor (SF) CONNECTIONS 8 Primary heat exchanger R return Heating 10 return sensor (SR) M flow Heating Heating 11 Water pressure transducer...

  • Page 13: Main Components

    MAIN COMPONENTS (fig. 3) 1 Control panel 2 Safety thermostat 3 Heating flow sensor (SM) 4 Ignition transformer 5 Ignition electrode 6 Primary heat exchanger 7 Air release vent 8 Exhaust sensor (SF) 9 Ionisation electrode Gas mixer 1 1 1 2 Pump 1 3 Collector signal 14 Pressure probe Fig. 3 APPROXIMATE MINIMUM DISTANCES ≥ 5 ≥ 3 CAUTION These minimum clearances must be maintained also in considera-...

  • Page 14: Boiler Electrical

    (24 VAC) CONNECTOR SPARE PART CODES: F1-2 Fuse (4 AT) TA1 Zone 1 environment thermostat TRA Ignition transformer TA2 Zone 2 environment thermostat code 6319162 Boiler pump D.H.W. sensor L. 2000 (optional) code 6319160 Remote control code 6319164 EA Ignition electrode SIME HOME (optional) code 6316203 ER Ionisation electrode External sensor (optional) code 6316202 EV1-2 Gas valve coil Programming clock (optional) code 6316204 Safety thermostat Remote alarm CN10 code 6319165 SF Exhaust temperature sensor Zone valve CN12...
  • Page 15 INSTALLER INSTRUCTIONS CONTENTS INSTALLATION..............................16 CHARACTERISTICS ............................28 COMMISSIONING, USE AND MAINTENANCE ......................36 COMMISSIONING CHECKLIST ..........................44 EXPLODED VIEWS .............................45 REPLACEMENT OF PARTS ..........................52 BOILER REGISTRATION ............................54 IMPORTANT When carrying out commissioning of the boiler, you are highly recommended to perform the following checks: – Make sure that there are no liquids or inflammable materials in the immediate vicinity of the boiler. – Make sure that the electrical connections have been made correctly and that the earth wire is connected to a good earthing system. – Open the gas tap and check the soundness of the connections, including that of the burner. – Make sure that the boiler is set for operation for the type of gas supplied.

  • Page 16: Installation

    INSTALLATION The boiler must be installed in a fixed Furthermore, vents, with surface areas 1.2.2 Sequence/cascade boilers location and only by specialized and at least 3.000 sq. cm or 5.000 sq. cm (fig. 4 - fig. 4/a) qualified firms in compliance with all for gas with density over 0.8, must be instructions contained in this manual.
  • Page 17 INSTALLER PARAMETERS section. Next press, in the order shown This must be done after setting PAR 15 on The boiler is provided with the board the designated Master boiler to “0” RS-485 that permits to manage up to 8 On the “Master” boiler press any key to The display will be as shown. boilers in cascade and communication wake up the display. in MODBUS. The board is placed on the back of the Then press simultaneously the and control panel. Access the board and...
  • Page 18 Fig. 4/b...
  • Page 19 MODBUS mode (fig. 4/c) MURELLE HE 50 R I / E boiler. In this - Choose the communication configu- case, proceed as follows: ration suited to the MODBUS network The RS-485 board can be used for - Set the DIP SWITCH of the RS-485 board (PAR 17 INST) according to Table PAR MODBUS communication of every and the PAR 16 as indicated in the figure. 17 INST. COMUNICAZIONE MODBUS DIP SWITCH CONNETTORE MODBUS COMMUNICATION...
  • Page 20 MODBUS BOILER VARIABLES LIST Function Variable description Digital variables Boiler CH Enable/Request D R/W Request CH zone 1 Enable DHW preparation Boiler DHW Enable D R/W Not used Boiler Water Filling Function D R/W State CH zone 1 Boiler CH Mode State preparation DHW Boiler DHW Mode Boiler Flame Status...
  • Page 21 CASCADE+MODBUS mode (fig. 4/d) CONNETTORE CABLATO This mode allows for MODBUS commu- (cod. 6319173) nication of at least two boilers in cascade WIRED CONNECTOR and is performed by requesting another (cod 6319173) RS-485 board provided in the kit code 8092244. ATTENTION: Communication will occur only with the MASTER boiler, (boiler with PAR 15 = 0), interpreting the casca- de as a single heat capacity generator: x No.
  • Page 22 The gas valve is supplied ex factory with you may directly contact SIME TECHNI- the maximum demand, limiting pressure an inlet filter, which, however, is not loss between the gas meter and any CAL DEPARTMENT.
  • Page 23 EXHAUST The exhaust pipe can be connected to from the flange and the intake is con- existing chimneys. nected to separate exhaust ducts (fig. 7) The boiler is supplied with a 80mm When the boiler works at low temperatu- or with coaxial exhaust (fig. 8). gasket, which must be fitted over the re is possible to use normal chimneys at exhaust terminal prior to the flue being the following conditions: 1.5.3 Maximum usable length...
  • Page 24 Type C (separate ø 80 flues) WARNING: - The installation of the roof exit terminal (4) requires the removal of the two ø 60 and ø 100 reducers. - Before installing accessories, lubricate the internal part of gaskets with silicon-based products. Avoid using oils and greases.
  • Page 25 Type C (ø 80/125 coaxial exhaust) NOTES: - Installation requires the use of a condensation recovery (12) that must be connected to a water drain siphon (waste water). - Before installing accessories, lubricate the internal part of gaskets with silicon-based products. Avoid using oils and greases. - Inserting each supplementary 90°...
  • Page 26 NOTE The following information is an extract from AS/NZS 5601. This information is subject to copyright of the AGA and Standards Australia and is supplied only as a reference. Every installer should have a copy and be familiar with this standard before installing this appliance. MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS, FAN-ASSISTED FLUE TERMINALS, ROOM-SEALED APPLIANCE TERMINALS OR THE TERMINALS OF OUTDOOR APPLIANCES Openable...
  • Page 27 Respect the L and N polarities and the plete remote control of the boiler, except earth connection. lockout reset of the boiler. The boiler 1.6.4 Heat Demand by 230 V display will show the following message: NOTE: SIME declines all responsibility azione temperatura 13. Visualizzazione codice errore penultima anomalia for injury or damage to persons, ani- The heating demand can be controlled by mals or property, resulting from the...

  • Page 28: Characteristics

    ON/OFF KEYS (access to INST and OEM parameters) ON = Electricity supply to boiler is on PC CONNECTION OFF = Electricity supply to boiler is on but not To be used only with the SIME programming kit and only ready for functioning. However, the protec- by authorised personnel. Do not connect other electronic tion functions are active. devices (cameras, telephones, mp3 players, etc.) Use a SUMMER MODE KEY tool to remove the cap and reinsert after use.
  • Page 29 ACCESS TO INSTALLER’S INFORMATION For access to information for the installer, press the key (3 fig. 12). Each time the key is pressed, the display moves to the next item of information. If expansion boards (MIXED ZONE o INSOL) are connected, the related info will be displayed. If the key is not pressed, the system automatically quits the function. Please note the first press of any key acts to illuminate the display only. 1. Display of external temperature, only 9. Display fan speed in rpm x 100 (e.g. 4.800 and 1850 rpm) 1. Visualizzazione temperatura esterna 9. Visualizzazione numero giri ventilatore in rpm x 100 (es. 4.800 e 1.850 rpm) when external sensor connected solo con sonda esterna collegata 2. Visualizzazione temperatura sonda 2. Display of heating flow temperature sen- 10. Display of number of hours of functioning of the burner in h x 100 (e.g. 14000 and 10) 10. Visualizzazione ore di funzionamento del bruciatore in h x 100 (es. 14.000 e 10) mandata riscaldamento (SM) sor (SM) 3. Display of D.H.W. temperature sensor (SS) 3. Visualizzazione temperatura sonda 11. Display of number of times the burner has ignited x 1000 (e.g. 97000 and 500) 11. Visualizzazione numero di accensioni del bruciatore x 1.000 (es. 97.000 e 500) sanitario (SS) solo per caldaie istantanee only for instantaneous boilers 4. Display of auxiliary temperature sensor 12. Display of total number 4.
  • Page 30 18. Display of heating return temperature sensor (SR) 29. Display of valve operation with board MIXED ZONE 2 (respectively ON and OFF) 18. Visualizzazione valore sonda ritorno riscaldamento (SR) 29. Visualizzazione comando chiusura valvola con schedino ZONA MIX 2 (rispettivamente ON e OFF) 19. Display of the Cascade flow temperature value( when fitted) 30. Display solar probe temperature value S1 with solar board INSOL 30. Visualizzazione valore temperatura sonda solare S1 19. Visualizzazione valore sonda collettore cascata con schedino solare INSOL 20. Display delivery probe value mixed with board MIXED ZONE 31. Visualizzazione valore temperatura sonda solare S2 31. Display solar probe temperature value S2 with solar board INSOL 20. Visualizzazione valore sonda mandata impianto miscelato 1 (input S2) con schedino solare INSOL con schedino ZONA MIX 1 (ingresso S2) 21. Display safety thermostat MIXED ZONE (input S1) respecti- 32. Visualizzazione valore temperatura sonda solare S3 21. Visualizzazione termostato sicurezza ZONA MIX (ingresso S1) 32. Display solar probe temperature value S3 with solar board INSOL con schedino solare INSOL vely ON and OFF rispettivamente ON e OFF 33. Display solar relay R1 with solar board INSOL (respectively ON and OFF) 33. Visualizzazione relè solare R1 con schedino solare INSOL 22. Display of pump operation with board MIXED ZONE (respectively 22.
  • Page 31 5 = Heat pump the default parameters can be changed 6 = Zone 2 valve with the keys and Luminous bar indicating presence 0 = Disabled The standard display returns automati- of voltage 1 = Enabled cally after 60 seconds, or by pressing one Allocation of SIME HOME channels 0 = Not assigned 1 = Circuit 1 of the control keys (2 fig. 12). es. 14.000 e 10) 2 = Three-zone circuit Fan rpm Step ignition 0,0 ... 81 rpmx100 0,1 from 0,1 to 19,9 1 from 20 to 81 2.3.1 Replacing the board or Long chimneys 0 ... 20...
  • Page 32 BOILER PAR 2 PARAMETERS INSTALLER Instantanious with diverter valve and flowmeter EXPANSION CARD I nstantanious with diverter valve, PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT flowmeter and solar system MEASUREMENT UNIT SETTING Number of expansion boards 0 ... 3 Remote control cylinder with Mix valve stroke time 0 ... 199 10 sec. d iverter valve and cylinder sensor Priority of D.H.W. over mixed zone 0 = Paralle T version (LOW INERTIA) 1 = Absolute Floor screed drying( see 4.5.2) 0 = No activated On board DHW cylinder, 1 = Curve A diverter valve and DHW sensor 2 = Curve B 3 = Curve A+B (LOW INERTIA) Type of solar system 1 ... 7 ∆...
  • Page 33 If after three attempts to light, rantee maximum flexibility in use of cuit, the boiler will not function. the ignition is not detected, the boiler the system. will lockout. this can be due to: – Interface with the following electro- nic systems: remote control SIME ELECTRONIC – Lack of gas HOME, thermal regulator RVS, con- IGNITION The ignition electrode will discharge nected to a management card of for max. 10 seconds. If the burner...
  • Page 34 In the case of a sudden loss of voltage, HEAD AVAILABLE shown as a function of rate of flow in the the burner will immediately switch off. TO SYSTEM (fig. 14) graph in fig. 14. When voltage returns, the boiler will automatically start up again. Residual head for the heating system is 1000 1500 2000 2500 3000 PORTATA (l/h)
  • Page 35 “MURELLE HE 50 R I/E” WITH KIT COMPENSATOR CODE 8101541 AND DHW CYLINDER (fig. 15) 1 Gas valve 2 Condensation drain trap 3 DHW Cylinder pump (not supplied) 4 Fan 5 Heating flow sensor (SM) 6 Safety thermostat 95°C 7 Exhaust sensor (SF) 8 Primary exchanger 10 Heating return sensor (SR) 11 Water pressure transducer 12 Auto air vent...

  • Page 36: Commissioning, Use And Maintenance

    COMMISSIONING, USE and MAINTENANCE INSTALLATION,SERVICING AND ALL RE- maximum rate as described in boiler parameter settings are cor- PAIRS MUSTBE CARRIED OUT BY ONLY 3.5.1(chimney sweep) rect, proceed as shown in 3.2.2 AUTHORISED PERSONS. With the boiler operating in the ma- Any adjustments should be done in ximum rate condition check that the small steps and adjustments of no operational (working) gas pressure more than 1/8th of a turn should COMMISSIONING INSTRUCTIONS at the inlet gas pressure test point...
  • Page 37 GAS CONVERSION (fig. 17) This operation must be performed by To change the fuel to UNIVERSAL LPG, it 2) Press the button for a few seconds authorised personnel using original is necessary to set SET 45, by pressing Sime components. the key The standard display will automatically To convert from natural gas to ULPG or return after 10 seconds. 3) Identify the CO values at max. power...
  • Page 38 Codice/Code 8104976-78 ATTENTION Modello/Model MURELLE HE 50 R I/E Before removing or refit- Matricola/Serial n. 9999999999 ting the front panel of the PAR 1 = 5 (G20) / 13 (ULPG) boiler, open the small PAR 2 = 5 upper plastic door. Fig. 19 DISASSEMBLING val and inspection of the burner and its...
  • Page 39 3.5.1 Chimney sweep function (fig. 21) To check boiler combustion, press the installer’s key for a few seconds. The chimney sweep function will switch on and will continue for 15 minutes. From that moment, the boiler will start working in heating mode at maximum power, with cut off at 80°C and re-igni- tion at 70°C (ATTENTION! Temperature may reach excessive values when using unprotected low temperature plants.
  • Page 40 FUNCTIONING ERRORS Apre Circuito When there is a functioning anomaly, an Circuito riscaldamento 2 alarm appears on the display and the riscaldamento 2 blue luminous bar may becomes red. Descriptions of the errors with relative alarms and solutions are given below: Circuito riscaldamento 2 – LOW WATER PRESSURE ERRORS ALARM 02 (fig. 23/a) Circuito Circuito riscaldamento 3...
  • Page 41 Apre – SAFETY/LIMIT THERMOSTAT ERROR ALARM 07 (fig. 23/f) If the connection with the safety ther- Circuito mostat/limit thermostat is interrupted, riscaldamento 2 the boiler will stop; the flame control will remain waiting to be switched off for one minute, keeping the system pump on for that period. If, the ther- mostat connection is restored within the minute, the boiler will start up Circuito Circuito...
  • Page 42 zone) Apre Circuito Circuito riscaldamento 2 – FAN ERROR “ALL 15” (fig. 23/m) – SAFETY THERMOSTAT INTERVEN- – AUXILIARY SENSOR ERROR (S3) “ALL riscaldamento 2 The fan speed does not fall within the TION SECOND MIXED ZONE “ALL 22” 26” (fig. 23/20) (fig. 23/s) rated speed range. When the solar probe is open or short If the error conditions persists for two When a mixed zone board is connected circuited, on the display the anomaly minutes, the boiler activates a forced...
  • Page 43 TION ERROR “ALL 32” (fig. 23/w) CAUTION: In the event of sequence/ca- scade connection, error codes 70 and 71 When the boards connected to the RS-485 are not enough and/or at least one of them will appear on the SIME HOME remote it is not mixing zone board, the boiler stops control display: and anomaly ALL 32 is displayed. The boiler restarts when the boiler - ALARM 70...

  • Page 44: Commissioning Checklist

    COMMISSIONING BOILER CHECK LIST A suggested method of commissioning the boiler, actual method can vary according to the boiler make type and the installation. The boiler must always be installed , and commissioned by an qualified gas technician. The installer certifies that this Boiler has been installed to the manufacturer’s instructions, has been filled, commissioned and is ready for use. No. Description ✔ when done Read carefully the instruction manuals supplied with this boiler. BEFORE INSTALLING THIS BOILER FLUSH OUT THE PIPES UNTIL CLEAN WATER IS ACHIEVED. Turn off all services to this boiler - water, gas and power. Install the boiler as shown in the instructions following and connect all services. Turn on water to fill system, check for leaks regularly and bleed air from all points. Bleed the air from all the pumps in the system, and rotate the impeller shaft Check that all radiators valves are open, all lock shields remove the thermostatic valve heads, fully open. Turn ON gas, bleed air out at the isolation valve union. Reseal and check for gas leaks. Turn gas OFF. Turn electricity on at the power point. At the boiler front panel set the temperature setting to the lowest setting, switch boiler to ON position. The “Power on” Indicator should light. Turn the boiler off at the front panel. Turn the room thermostat to the manual ON position set the temperature to a high level so that it do es not switch off during the commissioning phase. The thermostat will unusually click and shows an Indicator in the window. Switch the boiler ON at the boiler front panel control. Boiler should start fan, pump and ignite gas. If it fails first few times this may be just residual air In the gas line. A noisy water pump indicates there is air in the water pipes. Boiler lights and heats the water. Check gas flame is the correct colour and for gas and water leaks as the system heats up. Check that heat is going to all radiators through the manual or thermostatic first and return via the lockshield valve. If not STOP fix NOW and any leaks. Allow the boiler to heat up to the set temperature and switch off. Re-adjust the boiler temperature to a mid temperature point. CAUTION, If this is connected to a floor heating system. The boiler should re light and ...

  • Page 45: Exploded Views

    EXPLODED VIEWS...
  • Page 48 8104976/77 MURELLE HE 50 R I ------------------------------------------------------------------------------------------------------------------------------------ Pos. Code Description ------------------------------------------------------------------------------------------------------------------------------------ 6138533 Right hand side frame part 6138632 Left hand side frame part 6255431 Expansion vessel lower support 6010864 Water trap bracket 6256750 Transformer fixing bracket 6138897 Frame assembly lower side 6266081 Rear panel 6256751...
  • Page 49 ------------------------------------------------------------------------------------------------------------------------------------ Pos. Code Description ------------------------------------------------------------------------------------------------------------------------------------ 6227438 Flowing pipe to C.H. system 6226619 Spring for heat exchanger connection 6146701 100°C safety stat 6022010 Sensor gasket 6231351 Plunged sensor 6040206 Pressure relief valve 1/2" 4 bar 2030255 Gasket Ø 12,5x18,5x3 6157623 Pressure relief valve drain pipe 6017211 Manual air vent 1/4"...
  • Page 50 8104978/79 MURELLE HE 50 R E ------------------------------------------------------------------------------------------------------------------------------------ Pos. Code Description ------------------------------------------------------------------------------------------------------------------------------------ 6138533 Right hand side frame part 6138632 Left hand side frame part 6255431 Expansion vessel lower support 6010864 Water trap bracket 6256750 Transformer fixing bracket 6138897 Frame assembly lower side...
  • Page 51 ------------------------------------------------------------------------------------------------------------------------------------ Pos. Code Description ------------------------------------------------------------------------------------------------------------------------------------ 6227438 Flowing pipe to C.H. system 6226619 Spring for heat exchanger connection 6146701 100°C safety stat 6022010 Sensor gasket 6231351 Plunged sensor 6040206 Pressure relief valve 1/2" 4 bar 2030255 Gasket Ø 12,5x18,5x3 6157623 Pressure relief valve drain pipe 6017211 Manual air vent 1/4"...

  • Page 52: Replacement Of Parts

    REPLACEMENT OF PARTS The boiler certification and warranty will be void Remove the four fixing bolts and remove the fan. RHS panel. should spares or replacement parts be used Inspect the gasket and replace if necessary. Isolate the flow and return valves, and drain the that are not supplied by Sime Ltd, and only suit- Fit the fan and replace in reverse order. boiler using the drain vents provided. ably qualified personnel are permitted to work On completion a flue gas analysis must be Protect any electrical equipment from possible on gas appliances. taken. See section 3- Commissioning. spills of system water. Ensure that the boiler is isolated from the gas Disconnect the electrical connection.
  • Page 53 Remove the gas pipe securing nut at base of Apply heat conducting paste to the replace- 6.11  IGNITION ELECTRODE boiler ment stat. Disconnect the gas connection at then fan Refit in reverse order. Isolate the electrical and gas supply. Remove the gas valve and pipe assembly from Remove the ignition transformer cover fixing the boiler screws. Remove the pipework from the gas valve and fit Disconnect the ignition electrode wiring.

  • Page 54: Boiler Registration

    BOILER REGISTRATION IMPORTANT INFORMATION Please read before Installation. Fill in and retain with the boiler for future use. LOG BOOK - Installation, Commissioning and Service 1. Installation Details Owner -name Installation Address -Street City State Installation Phone Number Contact and Phone Number Sime Product - Model Serial Number refer to data plate Gas Type Natural Gas ULPG Internal External Gas pressure Central Heating. Settings Adjusted output setting The System pipes MUST BE FLUSHED before the connecting this boiler System FLUSHED before New...
  • Page 57 NOTE...
  • Page 58 NOTE...
  • Page 60 Fonderie Sime S.p.A - Via Garbo, 27 - 37045 Legnago (Vr) Tel. +39 0442 631111 - Fax +39 0442 631292 - www.sime.it...
