Table 5. Evaluation Board Layer Descriptions
Layer
Description
Blue (Top)
Top-of-board metal traces and ground plane. See Figure 7.
Red (Bottom)
Bottom-of-board metal traces and ground plane. Note that the top-view is shown in Figure 8. Silkscreen text is shown for
orientation purposes only; text does not appear on bottom of board.
Figure 8. Evaluation Board Layout—Bottom Layer
Rev. A | Page 9 of 12
ADD8754-EVAL
