5.7 Diagnostic

Print Config.
Dump Mode
Menu Diagnostic Printhead
Diag Gap
Display
Diag Black Mark
Sensor
Diag Ribbon End
Diag Media
Item Description
Print current printer configuration to the label. The configuration printout contains printhead test pattern, which is useful
Print Config.
for checking the dot damage on the printhead heater.
Captures the data from the communications port and prints out the data received by printer. In the dump mode, all
characters will be printed in 2 columns. The left side characters are received from your system and right side data are
Dump Mode
the corresponding hexadecimal value of the characters. It allows users or engineers to verify and debug the program.
Dump mode requires 4" width paper.
Printhead Check printhead's temperature and bad dots.
Display Check LCD's color state.
Sensor Check sensors intensity and reading state.
