6. GPIO Command Settings

6.1 SET GPO

Description
Use this command to send out the GPIO signals by the printer.
Syntax
SET GPOn signal state, delay0, pulse0, delay1, pulse1, function condition
Parameter Description
n = 1 ~ 7
n
Seven dedicated outputs are available for the desired function conditions.
HIGH
LOW
Signal state
POS
NEG
After detecting the following function condition, the printer will wait this period of time before sending out the "true"
Delay0 output signal.
Unit: millisecond. Maximum: 32000.
Pulse width corresponding to the function condition becoming "true". (Ignored for level-type signals.)
Pulse0
Unit: millisecond. Maximum: 32000.
Goes the high level signal when the following function condition is detected.
Goes the low level signal when the following function condition is detected.
Goes the positive pulse signal when the following function condition is detected.
Goes the negative pulse signal when the following function condition is detected.
